Description

Leviton PT5FF-N Poke-Through Cover, Nickel

Poke-Through Cover, Nickel

Furniture Feed Cover For Use With Leviton 5Ó Poke Through Floor Box (PT500) Only; Includes 2 Screw Caps Ð 1 Large Cap For Accommodating Data (1.5" Diameter Cap), And 1 Cap For Accommodating Power (0.75" Diameter Cap); Also Includes Pre-Assembled Gasket And Mounting Screws, Nickel

Only three cover assembly screws allow for easy installations and removals
Accommodates power and data furniture feeds
ADA-Complaint
Available in nickel, brass, black or gray powder coat

*Poke-Through covers are sold separately from the PT500 system

*Poke-Through covers come with low voltage divider

Environmental Specifications

Duration Of Fire Protection: Certified for Fire Resistance in 1, 1-1/2 & 2hr fire rated concrete floors
Operating Temperature: -40¡C to 70¡C

Material Specifications

Cover Material: Aluminum

Mechanical Specifications

Dimensions: 8.38Ó Diameter X 0.36" High

Product Features

Color: Nickel
Device Type: Furniture Feed Cover

Gasket: Pre-installed on Cover, O-rings included with screw caps
Openings: ¯ .75Ó, ¯ 1.50Ó NPS
Type: Poke-Through

Standards & Certifications

Applicable Standards: UL514A, UL263, CSA C22.2 No. 18.1
Certification/Listing: cULus
UL File No.: E92327, R40253

Warranty

Warranty: 2-Year Limited

Environmental Specifications

Duration Of Fire Protection: Certified for Fire Resistance in 1, 1-1/2 & 2hr fire rated concrete floors
Operating Temperature: -40¡C to 70¡C

Material Specifications

Cover Material: Aluminum

Mechanical Specifications

Dimensions: 8.38Ó Diameter X 0.36" High

Product Features

Color: Nickel
Device Type: Furniture Feed Cover

Gasket: Pre-installed on Cover, O-rings included with screw caps
Openings: ¯ .75Ó, ¯ 1.50Ó NPS
Type: Poke-Through

Standards & Certifications

Applicable Standards: UL514A, UL263, CSA C22.2 No. 18.1
Certification/Listing: cULus
UL File No.: E92327, R40253

Warranty

Warranty: 2-Year Limited
