Leviton OSWHB-IAW Discontinued Infrared Aisle (High Bay) Occupancy Sensor Made in USA
Color: White
Feature: Aisle High Bay
Grade: Commercial
Made in USA: Yes
Mount: Wall
Mounting: Wall Mount
Mounting Height (Ft.): 8-10 FT
Pattern Degrees: 08
Product Line: OSWHB
Sensor Technology: Passive Infrared (PIR)
Sensor Type: Occupancy
Time Delay: 30s-30m
Title 24 Compliant: Yes
Color: White
Feature: Aisle High Bay
Grade: Commercial
Made in USA: Yes
Mount: Wall
Mounting: Wall Mount
Mounting Height (Ft.): 8-10 FT
Pattern Degrees: 08
Product Line: OSWHB
Sensor Technology: Passive Infrared (PIR)
Sensor Type: Occupancy
Time Delay: 30s-30m
Title 24 Compliant: Yes
Discontinued Infrared Aisle (High Bay) Occupancy Sensor Made in USA
Discontinued
Discontinued Product. High-bay, PIR, Occupancy Sensor, Wall Mounted, 24VDC, 15mA power consumption, 30' mounting height, 55' length x 7' width (major motion only), Red LED=PIR, auto adapting, walk-through, time delay 30s-30m, test mode (6s time delay for 15m with auto exit), connect gray wire for photocell ambient light hold-off, 360 degree harmonic wheel (rotatable), mounting height 8'-10', Patented Canopy Knuckle for versatile wall and ceiling mounting options, cUL/NOM/ANCE listed, Color: off-white, Made in USA
Product Features
Application: Cafeterias, Hallways, Loading docks, Parking garages, Stairwells, Storage rooms, Warehouses, WorkspacesColor: White
Feature: Aisle High Bay
Grade: Commercial
Made in USA: Yes
Mount: Wall
Mounting: Wall Mount
Mounting Height (Ft.): 8-10 FT
Pattern Degrees: 08
Product Line: OSWHB
Sensor Technology: Passive Infrared (PIR)
Sensor Type: Occupancy
Time Delay: 30s-30m
Title 24 Compliant: Yes
Performance Specifications
Coverage (Sq.Ft.): 55FT x 7FT @ 30FT HeightElectrical Specifications
Current Consumption: 20mA Output Voltage: 24 VDC active high logic control signal with short circuit protection
Power Consumption: 15mA Stand-by
Voltage: 24 VDC
Voltage Type: Low Voltage
USMCA Compliant: Yes
Size: Height 6.43" (163.32mm), Depth 4.67" (118.61mm), Sensor Width 2.80" (71.12mm), Base Width 4.23" (107.44mm)
Relative Humidity: 0% to 95% non-condensing
Power Consumption: 15mA Stand-by
Voltage: 24 VDC
Voltage Type: Low Voltage
Standards and Certifications
Listings: cUL/US Certified, can be used to comply with ASHRAE 90.1 and Title 24, Part 6 occupancy sensing requirementsUSMCA Compliant: Yes
Mechanical Specifications
Mounting Type: Wall MountSize: Height 6.43" (163.32mm), Depth 4.67" (118.61mm), Sensor Width 2.80" (71.12mm), Base Width 4.23" (107.44mm)
Environmental Specifications
Operating Temperature: 32¡ to 104¡F (0¡ to 40¡C)Relative Humidity: 0% to 95% non-condensing
Type
Product Type: Occupancy SensorWarranty
Warranty: 5-Year LimitedProduct Features
Application: Cafeterias, Hallways, Loading docks, Parking garages, Stairwells, Storage rooms, Warehouses, WorkspacesColor: White
Feature: Aisle High Bay
Grade: Commercial
Made in USA: Yes
Mount: Wall
Mounting: Wall Mount
Mounting Height (Ft.): 8-10 FT
Pattern Degrees: 08
Product Line: OSWHB
Sensor Technology: Passive Infrared (PIR)
Sensor Type: Occupancy
Time Delay: 30s-30m
Title 24 Compliant: Yes
Performance Specifications
Coverage (Sq.Ft.): 55FT x 7FT @ 30FT HeightElectrical Specifications
Current Consumption: 20mA Output Voltage: 24 VDC active high logic control signal with short circuit protection
Power Consumption: 15mA Stand-by
Voltage: 24 VDC
Voltage Type: Low Voltage
USMCA Compliant: Yes
Size: Height 6.43" (163.32mm), Depth 4.67" (118.61mm), Sensor Width 2.80" (71.12mm), Base Width 4.23" (107.44mm)
Relative Humidity: 0% to 95% non-condensing
Power Consumption: 15mA Stand-by
Voltage: 24 VDC
Voltage Type: Low Voltage
Standards and Certifications
Listings: cUL/US Certified, can be used to comply with ASHRAE 90.1 and Title 24, Part 6 occupancy sensing requirementsUSMCA Compliant: Yes
Mechanical Specifications
Mounting Type: Wall MountSize: Height 6.43" (163.32mm), Depth 4.67" (118.61mm), Sensor Width 2.80" (71.12mm), Base Width 4.23" (107.44mm)
Environmental Specifications
Operating Temperature: 32¡ to 104¡F (0¡ to 40¡C)Relative Humidity: 0% to 95% non-condensing
Type
Product Type: Occupancy SensorWarranty
Warranty: 5-Year Limited
