Leviton 117A00-1 Omni-Bus Interface Translator DIN Rail Module
Omni-Bus Interface Translator DIN Rail Module
Omni-Bus is a distributed control system for lights, shades, fans, shutters, pumps, and more. Utilizing the worldwide DIN rail standard for mounting, Omni-Bus controls CFL, LED, electronic low voltage, Halogen, and incandescent lighting. Output devices are rated for 110/220/240V 50-60Hz markets unless otherwise noted. All wall stations are 24VDC and below. Modular Omni-Bus components can be located where needed to save wiring and installation costs. Elegant, multi-button programmable wall stations eliminate the expense of in-wall high voltage wiring to multi-way switches.
- The ÒgatewayÓ of the Omni-Bus system, this device allows Leviton Security & Automation Controllers (Omni LTe, Omni IIe, OmniPro II, Lumina, and Lumina Pro) to interface with an Omni-Bus network
- Built-in radio receiver for use with wireless switch interfaces
- 113A00-2, 113A00-4 and 113A00-7 and keyfob remotes, 125A00-1 and 125A00-2
- Features an Ethernet port, USB port for programming, and serial port
- Bus side supply voltage: 16-24VDC (via bus network cable or external supply input)
- Bus side supply current: 250mA maximum
- Ethernet port: 10BASE-T
- Number of simultaneous TCPIP connections: 8 maximum
- USB port: 1.1 Full speed
- RF Receiver: 433.92MHz
- Ambient Temperature: 0 Ð 40 ¼C (32 Ð 104 ¼F)
- Ingress Protection: IP20
- Compatible with the following Leviton controllers:
- OmniPro II, Omni IIe, Omni LTe, Lumina Pro, Lumina
- All modules are CE, FCC, UL (ETL), SASO, and C-Tick approved
- Leviton Part Number: OB171
