ALEDFC52

RAB Lighting

$576.00
(No reviews yet) Write a Review
SKU:
ALEDFC52
UPC:
19813029337
Availability:
Usually ships within 1 week.
Weight:
29.10 LBS
Shipping:
Calculated at Checkout
sub-tech:
LED
Kelvin:
5000K
color:
Bronze
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
52W
Color Temp:
5000K (Cool)
Lumens:
7,325 lm
Efficacy:
128.5
Color Accuracy:
72 CRI
L70:
100,000 Hours
Type:
Constant Current
V120:
0.51A
V208:
0.33A
V240:
0.29A
V277:
0.24A
Input Watts:
57W
sub-tech:
LED
Kelvin:
5000K
color:
Bronze
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
52W
Color Temp:
5000K (Cool)
Lumens:
7,325 lm
Efficacy:
128.5
Color Accuracy:
72 CRI
L70:
100,000 Hours
Type:
Constant Current
V120:
0.51A
V208:
0.33A
V240:
0.29A
V277:
0.24A
Input Watts:
57W
Adding to cart… The item has been added
Compliance
UL ListedSuitable for wet locations. Suitable for mounting within 4 ft of the ground.
IESNA LM-79 & LM-80 TestingRAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC ListedThis product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: P0000170T
Electrical
DriverConstant Current, Class 2, 120-277V, 50-60Hz, 120V: 0.51A, 208V: 0.33A, 240C: 0.29A, 277V: 0.24A
Dimming DriverDriver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD13.33% at 120V
Power Factor99.3% at 120V, 97.2% at 277V
Surge Protection6kV
Performance
Lifespan100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage EquivalencyEquivalent to 250W Pulse Start Metal Halide
Construction
IES ClassificationThe Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area.
Ambient TemperatureSuitable for use in up to 40°C (104°F)
Cold Weather StartingThe minimum starting temperature is -40°C (-40°F)
HousingPrecision die-cast aluminum housing, lens frame
ArmDie-cast aluminum with wiring access plate
GasketsHigh-temperature silicone
EPA1 Fixture: 1.52 Fixtures at 90°: 2.42 Fixtures at 180°: 2.93 Fixtures at 90°: 3.24 Fixtures at 90°: 3.2
FinishFormulated for high durability and long-lasting color
Green TechnologyMercury and UV free. RoHS-compliant components.
LED Characteristics
LEDsTwo (2) multi-chip, high-output, long-life LEDs
Color Consistency7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color StabilityLED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color UniformityRAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Optical
BUG RatingB1 U0 G1
