APPLICATION:
Ideal for commercial and industrial facilities where economy, appearance and the ultimate ease of installation and maintenance are desired. LED die-cast aluminum series utilizes a unique illumination design in an architecturally pleasing housing.
FEATURES:
- Low Profile thin aluminum housing with universal mounting kit.
- Innovative snap-together design allows for fast and easy installation.
- Letters 6Ó height with 3/4Ó stroke.
- Field selectable knockout Chevron directional indicators.
- 90+ minute emergency operation.
- Available in white, black or aluminum housing.
MOUNTING:
- Aluminum mounting canopy included for top or end mount.
- Universal knockout pattern on back plate for wall mount.
ELECTRICAL:
- 120/277V dual voltage operation standard.
- Charge rate and power ÒONÓ LED indicator light and push-to-test switch for mandated code compliance testing.
LAMPS:
- LED lamps are operating in normal (AC input) and emergency (DC input) modes.
- Ultra-bright, energy efficient, long-life Red or Green LEDs with more then 10 year lifecycle.
- LEDs have a minimum rated lamp life of 100,000 hours.
BATTERY:
- Maintenance-free and rechargeable Ni-Cad battery on emergency (EM) units.
- Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
- Internal solid-state transfer switch automatically connects the internal battery to LEDs for minimum 90 minute emergency illumination.
LISTING:
- 5 years limited warranty on materials and all electronics.
- Certified to CEC under Title 20 Regulations.
- UL listed for damp locations. (0¡ - 50¡C / 32¡F - 122¡F)
- Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
- NFPA 70 compliant.
