nVent Hoffman P2K18108S ProLine G2 Industrial Packages Seismic, 1800x1000x800, Lt Gray, Steel
12-gauge (2.5 mm) roll-formed steel with welded corners, and hybrid frame profile for superior performance under load Consistent with Type-12 Industrial Packages, but reinforced in all directions using seismically capable components/accessories to withstand forces present in seismic areas with a Zone-4 risk assignment Frame features a 25-mm DIN standard, alternating rectangular and round hole pattern Single door includes robust 3-point latch system to maintain door closure during seismic activity, with gussets included at the top and bottom of the door to increase rigidity Seamless Polyurethane gasket provides a water-tight, dust-tight seal against moisture and contaminants Door bar system and two grounding studs present Single door left-hinged standard, with Key-locking Flush Swing Handle standard Galvanized Duro-Stand gland plate included 100-mm Fully-Sealed Base with seismic mounting into frame's welded steel corners Seismic Floor Mounting Brackets supplied loose for affixing enclosure to floor White painted full subpanel fully recessed in rear-most mounting position: EZ-Load Glide Blocks supplied only in the front to support rear-most subpanel position Top and bottom panel brackets, panel support brackets (side), and panel wedges to secure a populated subpanel are incorporated in the design Gussets mounted to the frame's door opening at the top and bottom White painted partial subpanels at top and bottom of frame's sides, unique seismic design Depth-mounted 3-row Grid Strap at mid-point of frame Solid Side Covers included standard
UL 508A Listed 508; Type 12; File Number E61997
cUL Listed per CSA C22.2 No. 94; Type 12; File No. E61997
