Mini Jacker Jack Plate / Outboard Motor Bracket
This cast aluminum offset type jack plate is designed for clamp-on mount outboard motors up to 35 HP. The Mini Jacker allows mounting of long shaft motors to shorter shaft transom boats. The mini-jacker stands off transom 4". The engine mounting surface is 11 1/2" wide x 10" high and features a vertical offset of 3". The overall width of transom mounting flanges is 17".
Super for skiffs, aluminum boats, and inflatables.
Clamp Style Small Outboard Jack Plate
Cast Aluminum Bracket
Marine Grade Transom Block
4 Setback 3 Vertical
Max Wt 150lbs Max HP-35
Packaging: individually boxed - open quantity
