Occupancy Sensor, PIR, Wall Switch, 2100SF, 120-277V, Black, Auto-ON/Auto-OFF Only, Decora¨

• Fits in standard wallbox and replaces single-pole wall switch. Gangable with other units.
• Low-profile design eliminates obtrusive Òscanning-deviceÓ look. Elegant Decora wallplates complement any interior for sleek aesthetics; uses Decora wallplates and coordinates with LevitonÕs popular line of Decora wiring devices.
• 180¡ field-of-view provides approximately 2100 square feet of coverage suitable for small offices, conference rooms, classrooms, lounges and a variety of commercial areas.
• Two dual element PIR sensors used to widen detection range.
• Segmented Fresnel lens provides optimum sensitivity and performance. Designed with an extensive Òminor motionÓ area where even slight body movements will be detected.
• Vandal resistant PIR lens.
• Horizontal field-of-view may be adjusted between 180¡ and 60¡ of arc by using integral blinders located on either side of the lens. No masking tape required.
• Red LED indicator light flashes when sensor detects motion to verify detection is active.
• Time Delay adjustment for delayed-OFF time settings of 30 seconds (for walking test), 10 minutes, 20 minutes, and 30 minutes. Allows customized adjustments to maximize lamp life and energy savings.
• Light Sensor Adjustable Ambient Light Override ranges from approximately 2 foot-candles (20 lux) to 500+ foot-candles (5000+ lux) to prevent lights from turning ON automatically during periods of ample natural light, increasing energy savings.
• Light sensor enables the load hold-OFF feature once level has been set.
• Vacancy confirmation - when the time out expires and the lights turn OFF a 30 second vacancy confirmation exists to turn the lights back ON.
• False detection circuitry.
• One unit can be used for 120V through 277V lighting. Compatible with both electronic and magnetic ballasts.
• Relay switches at the zero crossing point of the AC power curve to ensure maximum contact life and compatibility with electronic ballasts.
• Exclusive Leviton H.I.S. Circuitry. Specifically designed to handle todayÕs high inrush electronic ballast loads and offer unmatched durability and service.
• No neutral design is optional for retrofit applications.
