Leviton 5089-I gle Receptacle Outlet, Commercial Specification Grade, Indented Face, 15 Amp, 250 Volt, Back or Side Wire, NEMA 6-15R, 2-Pole, 3-Wire, Self-Grounding - Ivory

Leviton 5089-I gle Receptacle Outlet, Commercial Specification Grade, Indented Face, 15 Amp, 250 Volt, Back or Side Wire, NEMA 6-15R, 2-Pole, 3-Wire, Self-Grounding - Ivory

Leviton

(No reviews yet) Write a Review
SKU:
LEVITON-5089-I
Weight:
0.00 LBS
Call for price
Leviton 5089-I gle Receptacle Outlet, Commercial Specification Grade, Indented Face, 15 Amp, 250 Volt, Back or Side Wire, NEMA 6-15R, 2-Pole, 3-Wire, Self-Grounding - Ivory

Single Receptacle Outlet, Commercial Specification Grade, Indented Face, 15 Amp, 250 Volt, Back or Side Wire, NEMA 6-15R, 2-Pole, 3-Wire, Self-Grounding - Ivory

LevitonÕs line of Heavy-Duty Specification Grade receptacles are designed and manufactured to withstand the most demanding environments. Available in a wide variety of configurations, including isolated ground, tamper-resistant, etc., these Commercial Grade devices are the electrical contractor's choice for use in hotels, schools, hospitals and commercial office buildings.



AC Horsepower Ratings
At Rated Voltage: 1-1/2 HP

Electrical Specifications
Amperage: 15 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Self-Grounding
Pole: 2
Temperature Rise: Max 30C after 100 cycles OL at 150 percent rated current
Voltage: 250 VAC
Wire: 3

Environmental Specifications
Flammability: Rated V-2 per UL 94
Operating Temperature: -40¡C to 60¡C

Material Specifications
Body Material: Nylon
Clamp Nuts: Zinc-Plated Steel
Color: Ivory
Face Material: Nylon
Grounding Screw: Brass 8-32
Line Contacts: Brass Triple-Wipe .031 Thick
Strap Material: Zinc-Plated Steel
Terminal Screws: Brass 10-32

Mechanical Specifications
Product ID: Ratings are permanently marked on device
Terminal Accom.: 14-10 AWG
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Termination: Back or Side Wire

Product Features
Color: Ivory
Device Type: Single Receptacle Outlet
Feature 4: Indented Face
Grade: Commercial Specification Grade
NEMA: 6-15R

Standards and Certifications
ANSI: C-73
CSA C22.2 No. 42: File 152105
NEMA: WD-2 WD-6
NOM: 057
UL Fed Spec WC-596: File E13399
UL498: File E13399
Warranty: 10-Year Limited


AC Horsepower Ratings
At Rated Voltage: 1-1/2 HP

Electrical Specifications
Amperage: 15 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Self-Grounding
Pole: 2
Temperature Rise: Max 30C after 100 cycles OL at 150 percent rated current
Voltage: 250 VAC
Wire: 3

Environmental Specifications
Flammability: Rated V-2 per UL 94
Operating Temperature: -40¡C to 60¡C

Material Specifications
Body Material: Nylon
Clamp Nuts: Zinc-Plated Steel
Color: Ivory
Face Material: Nylon
Grounding Screw: Brass 8-32
Line Contacts: Brass Triple-Wipe .031 Thick
Strap Material: Zinc-Plated Steel
Terminal Screws: Brass 10-32

Mechanical Specifications
Product ID: Ratings are permanently marked on device
Terminal Accom.: 14-10 AWG
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Termination: Back or Side Wire

Product Features
Color: Ivory
Device Type: Single Receptacle Outlet
Feature 4: Indented Face
Grade: Commercial Specification Grade
NEMA: 6-15R

Standards and Certifications
ANSI: C-73
CSA C22.2 No. 42: File 152105
NEMA: WD-2 WD-6
NOM: 057
UL Fed Spec WC-596: File E13399
UL498: File E13399
Warranty: 10-Year Limited
