Name: Leviton 2420-B 20 Amp, 250 Volt 3-Phase, NEMA L15-20R, 3P, 4W, Flush Mtg Locking Receptacle, Industrial Grade, Grounding, All Black - BLACK
Brand: Leviton
SKU: LEVITON-2420-B
Availability: OutOfStock

Description

Leviton 2420-B 20 Amp, 250 Volt 3-Phase, NEMA L15-20R, 3P, 4W, Flush Mtg Locking Receptacle, Industrial Grade, Grounding, All Black - BLACK

20 Amp, 250 Volt 3-Phase, NEMA L15-20R, 3P, 4W, Flush Mtg Locking Receptacle, Industrial Grade, Grounding, All Black - BLACK

AC Horsepower Ratings

At Rated Voltage: 3 HP

Electrical Specifications

Amperage: 20 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Grounding
Phase: 3-Phase
Pole: 3
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 250 VAC
Wire: 4

Environmental Specifications

Environment: Corrosive
Flammability: Rated V-0 per UL 94
Operating Temperature: -40¡C to 60¡C

Material Specifications

Base Material: Valox
Color: Black
Face Material: Ultramid
Grounding Screw: Brass 8-32
Line Contacts: Brass .040 Thick

Strap Material: Nickel-Plated Brass
Terminal Screws: Brass 10-32
Yoke: Nickel-Plated Brass .050 Thick

Mechanical Specifications

Product ID: Ratings and NEMA I.D. permanently marked on device
Terminal Accom.: 14-8 AWG
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Termination: Back & Side

Product Features

Brand: V-0-Max
Color: Black
NEMA: L15-20R

Standards and Certifications

ANSI: C-73
CSA C22.2 No. 42: File LR-406
NEMA: WD-6
NOM: 057
UL Fed Spec WC-596: File E13399
UL498: File E13399
Warranty: Limited Lifetime Warranty
