RAB Lighting IVAT3-100LPA740ZH/7PR Ivelot T3 100W 10000L Pole 4K 70Cri Bz 347-480V Dim 7Pr, 4000K Neutral, 100000 Hour Life, IVAT3-100LPA740ZH/7PR or RAB

IVAT3-100LPA740ZH/7PR

RAB Lighting

$879.00
(No reviews yet) Write a Review
SKU:
IVAT3-100LPA740ZH/7PR
Availability:
Usually ships within 1 week.
Weight:
14.20 LBS
Shipping:
Calculated at Checkout
voltage:
480v
wattage:
100w
Kelvin:
4000K
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
94W
Color Temp:
4000K (Neutral)
Lumens:
10,326 lm
Efficacy:
109.7 lm/W
Color Accuracy:
73 CRI
L70:
100,000 Hours
Type:
Constant Current
Input Watts:
94.1W
voltage:
480v
wattage:
100w
Kelvin:
4000K
Spec Sheet:
Spec Sheet
Instructions:
Instructions
Watts:
94W
Color Temp:
4000K (Neutral)
Lumens:
10,326 lm
Efficacy:
109.7 lm/W
Color Accuracy:
73 CRI
L70:
100,000 Hours
Type:
Constant Current
Input Watts:
94.1W
Adding to cart… The item has been added
Compliance
UL ListedSuitable for wet locations
IESNA LM-79 & LM-80 TestingRAB LED luminaires have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80
Title 24 CompliantAn IVELOT edge-lit area light can be used with a motion sensor or photocell control option to comply with 2016 Title 24 Part 6 Section 130.2 (a,b,v)
IP RatingIngress protection rating of IP66 for dust and water
DLC ListedThis product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: S-VMFND7
Electrical
DriverClass 2, 50/60Hz, 480V 4kV standard, 10kV optional
Dimming DriverDriver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD13.13% at 480V
Power Factor95.1% at 480V
7-Pin ReceptacleANSI C136.41 7-pin receptacle, compatible with wireless control systems
Performance
Lifespan100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations at 25°C
LED Characteristics
LEDsLong-life, high-efficacy, surface-mount LEDs
Color StabilityLED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color UniformityRAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Cold Weather StartingThe minimum starting temperature is -40°C (-40°F)
Maximum Ambient TemperatureSuitable for use in up to 40°C (104°F)
HousingPrecision die-cast aluminum
IES ClassificationThe Type III distribution is ideal for roadway, general parking, and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area.
LensDiffused Polymethyl Methacrylate (PMMA)
Effective Projected AreaEPA = 0.61
FinishFormulated for high durability and long-lasting color
Green TechnologyMercury and UV free. RoHS-compliant components.
Installation
MountingUniversal pole adapter
