Craft Metal Products PL Plano Series - Pendant
Model Number Lamping Code Body Lamping Circuit Finish Diffuser Mounting Options IES PDF BIM FLX 4,800lm LED (37W) 1 PC AD ST
AC BL
D1
GKH 6,600lm LED (50W) 1 PC AD ST
AC BL
D1
EZR 8,400lm LED (57W) 1 PC AD ST
AC BL
D1
PL0624L
Dimensions:
¥ W 6
¥ HT 24
¥ OAH 36
(OverAll Height)
AC
D1
PL0636L
Dimensions:
¥ W 6
¥ HT 36
¥ OAH 72
(OverAll Height)
AC
D1
PL0648L
Dimensions:
¥ W 06
¥ HT 48
¥ OAH 72
(OverAll Height)
AC
D1
Scale
PRODUCT FEATURES
- Fabricated and welded metal housing
- Powder coated metallic finish
- UV stable, white acrylic cylinder diffuser (Standard)
- Optional specialty diffuser materials available
- Energy efficient LED lamping
- High power factor electronic LED driver
- Standard LED CCT is 3000 Kelvin - contact us for alternate color temperature availability
- Standard LED CRI is 80 - contact us for alternate CRI availability
- Standard LED dimming is 0-10v
- Optional line voltage (Triac or ELV) LED dimming is available - consult for compatibility
- Fixture is Chain or Stem hung (extra length may be added, specify OAH) (OAH - Over All Height - is the length from the ceiling to the bottom of the fixture.)
- Mounts to standard electrical junction box (by others), Box may require additional structural support (by others)
- For slopes greater than 35 degrees (from horizontal) order steep pitch adapter (Stem only)
- UL / cUL or ETL / cETL listed
- Contact Us for more lamping options.
Abbreviation Key
Dimensions
W
Width
HT
Height
OAH
OverAll Height
Finish Types
PC
Powder Coat
Diffuser Types
AD
Standard Acrylic Diffuser
Mountings
ST
Stem
AC
Air Craft Cable
Dimming Types
D1
LED 0-10V low voltage control dimming
Options
