| Field Adjustability |
| Field Adjustable | Color temperature selectable by 3000K, 4000K and 5000K |
| Compliance |
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| IP Rating | Ingress protection rating of IP65 for dust and water |
| Electrical |
| Driver | Constant Current, Class 1, 120-277V, 50/60Hz, 120V: 0.67A, 208V: 0.38A, 240V: 0.33A, 277V: 0.29A |
| Dimming Driver | Driver includes wiring for 0-10V dimming systems. Dim as low as 10%. |
| THD | 9.56% at 120V, 10.13% at 277V |
| Power Factor | 99.9% at 120V, 93% at 277V |
| Photocell | 120-277V selectable photocell that can be turned on and off. |
| Surge Protection | 6kV |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Housing | Precision die-cast aluminum |
| Effective Projected Area | EPA = 0.79 |
| Lens | Tempered glass |
| Reflector | Polycarbonate |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Robust knuckle mount with 180° adjustable swivel arm. Tilt angle in 10° increments. |
| Optical |
| NEMA Type | NEMA Beam Spread of 7H x 7V |
| Performance |
| Wattage Equivalency | Equivalent to 400W Metal Halide |
