The Vaporproof.CM is a heavy-duty LED lighting solution. This LED lighting fixture features heavy-duty die-cast aluminum housing with a clear glass lens.
Applications:
Hazardous Environments, Warehouses, Walkways and a variety of other indoor and outdoor lighting applications. Electrical System Characteristics / Data Standard AC input: 120-277 VAC EMI filter: 47CFR, part 2, part 15 Power factor: .>9 Total harmonic distortion: <20% Surge protection: IEC/EN 61000-4-5 EMC test standard Specifications CSA Listing: Wet Locations IP Rating: 65 Length: 11.5” Width: 5.13”
Fixture
Grey Lens: Clear Glass Mounting: Ceiling Diffusion: None 1 Ordering Information Sample Catalog Number: LIN-024-FIN-WW-B-MT-VCM LIGHT ENGINE DRIVE CURRENT COLOR TEMPERATURE VOLTAGE FIXTURE CODE OPTIONAL UPGRADES OPTIONAL BEAM SPREAD LIN-024-FIN LIN-024-FIN A B CW – COOL WHITE (5700K TYPICAL) NW – NEUTRAL WHITE (4000K TYPICAL) WW – WARM WHITE (3000K TYPICAL) MT VCM– VAPORPROOF.CM HV1 – 480V UP TO 150W HV2 – 480V GREATER THAN 150W EM – EMERGENCY BATTERY BACKUP, 5W, 600 LUMENS, 90 MINUTES* EMC – EMERGENCY BATTERY BACKUP, COLD 23W, 2000, 90 MINUTES* FR – FROSTED LENS COL-[RAL] – CUSTOM COLOR COAT – CUSTOM COAT EPOXY – EPOXY COATING SGR1 – 100 -277V SURGE PROTECTOR SGR2 – 480V SURGE PROTECTOR 010V – 1-10V DIMMING FUNCTIONALITY STEP – STEP DIMMING FUNCTIONALITY *MUST PROVIDE EXACT VOLTAGE REQUIREMENT 80D – OPTIONAL 80° BEAM SPREAD Performance Summary Lumens Range: 3,576lm - 5,054lm Lumens Per Watt (Typical): 141 CRI: Minimum 70 CRI. Custom CRI available upon request. CCT (Typical): 3000K, 4000K, 5700K Manufactured in the U.S.
Construction Heavy-
duty die-cast aluminum housing, screw-on guard, chromate conversion coating and textured grey powdercoat. Optics High brightness, high efficiency LEDs. Color temperature options include Cool White (5700K typical), Neutral White (4000K typical) Warm White (3000K typical) with minimum 70 CRI. Custom RGBW colors available. 120° beam angle standard. Optional 80° beam angle available. Manufacturing Manufactured in beautiful Harbor City, CA. ARRA Compliant. NAFTA Compliant. Test and burn-in of 100% of all luminaries before shipment. No less than 8-years experience in manufacturing LED-based products. Note Specifications subject to change without notice. Actual performance may differ as a result of end-user environment application. Actual wattage may differ by +/- 8%.
Electrical System
Surge protection meets 10KV/5KA per ANSI/IEEEC62.41. Driver meets maximum harmonic distortion (THD) of 20% and is ROHS compliant. Power Factor = > 0.9. Mounting Ceiling mounting available for this fixture. Ambient Temperature -40°C to +65°C (-40°F to + 149°F). Operating Characteristics (Typical @5700K CCT) LIGHT ENGINE DRIVE LUMENS (T5) INPUT POWER (WATTS) LUMENS PER WATT LIN-024-FIN A 3,576 35.96 99.45 LIN-024-FIN B 5,064 35.96 140.87 2 ELECTRICAL Testing Compliance UL 1598 Issued: 2008/09/17 Ed:3 Rev:2012/10/17 UL Standard for Safety Luminaires CSA C22.2#250.0 Issued: 2008/09/17 Ed:3 Luminaires; General Instruction No.1 2010/01/11, General Instruction No. 2 2012/10/17. (ANSI/UL 8750). UL Standard for Safety for Light Emitting Diode (LED) Equipment for use in Lighting Products - First Edition; Dated 2009/11/18. 101514278LAX-001 revised 27-Jun-2014. Controls Controls include 480V for up to 150W light engines (HV1) and 480V for 150W-299W light engines (HV2). 100-722V (SGR1) and 480V (SGR2) Surge Protectors. 0-10V (010V) and Step (STEP) dimming functionality. Emergency Backup Battery (EM) and Emergency Battery Backup, Cold (EMC)
Driver Available
in A (350mA) drive current and B drive current (525 mA). Highly reliable. Suitable for dry, damp and wet locations.
Manufacturing
Manufactured in beautiful Harbor City, CA. ARRA Compliant. NAFTA Compliant. Test and burn-in of 100% of all luminaries before shipment. No less than 8-years experience in manufacturing LED-based products. Note Specifications subject to change without notice. Actual performance may differ as a result of end-user environment
