36w LED Vapor Proof PM Light (VPM) 100w Equivalent 5064 Lumens

Noribachi

$468.54
(No reviews yet) Write a Review
Availability:
Usually ships within 2-4 weeks
Weight:
0.00 LBS
Shipping:
Calculated at Checkout
Adding to cart… The item has been added

The Vaporproof.JM is a heavy-duty, energy-efficient LED lighting solution. This LED lighting fixture features aluminum housing with a tempered glass lens. Applications: Hazardous Environments, Storage Facilities, Recreational Areas and a variety of other indoor and outdoor lighting applications.

Electrical System

Characteristics / Data Standard AC input: 120-277 VAC EMI filter: 47CFR, part 2, part 15 Power factor: .>9 Total harmonic distortion: <20% Surge protection: IEC/EN 61000-4-5 EMC test standard Specifications CSA Listing: Wet Locations IP Rating: 65 Length: 12” Width: 5.13”

Fixture Information Housing:

Grey Lens: Clear Glass Mounting: Ceiling Diffusion: None 1 Ordering Information Sample Catalog Number: LIN-024-FIN-WW-B-MT-VPM LIGHT ENGINE DRIVE CURRENT COLOR TEMPERATURE VOLTAGE FIXTURE CODE OPTIONAL UPGRADES OPTIONAL BEAM SPREAD LIN-024-FIN LIN-024-FIN A B CW – COOL WHITE (5700K TYPICAL) NW – NEUTRAL WHITE (4000K TYPICAL) WW – WARM WHITE (3000K TYPICAL) MT VPM– VAPORPROOF.PM HV1 – 480V UP TO 150W HV2 – 480V GREATER THAN 150W EM – EMERGENCY BATTERY BACKUP, 5W, 600 LUMENS, 90 MINUTES* EMC – EMERGENCY BATTERY BACKUP, COLD 23W, 2000, 90 MINUTES* FR – FROSTED LENS COL-[RAL] – CUSTOM COLOR COAT – CUSTOM COAT EPOXY – EPOXY COATING SGR1 – 100 -277V SURGE PROTECTOR SGR2 – 480V SURGE PROTECTOR 010V – 1-10V DIMMING FUNCTIONALITY STEP – STEP DIMMING FUNCTIONALITY *MUST PROVIDE EXACT VOLTAGE REQUIREMENT 80D – OPTIONAL 80° BEAM SPREAD Performance Summary Lumens Range: 3,576lm-5,054lm Lumens Per Watt (Typical):

Construction

Heavy-duty die-cast aluminum housing, screw-on guard, chromate conversion coating and textured grey powdercoat. Optics High brightness, high efficiency LEDs. Color temperature options include Cool White (5700K typical), Neutral White (4000K typical) Warm White (3000K typical) with minimum 70 CRI. Custom RGBW colors available. 120° beam angle standard. Optional 80° beam angle available.

Controls Controls

include 480V for up to 150W light engines (HV1) and 480V for 150W-299W light engines (HV2). 100-722V (SGR1) and 480V (SGR2) Surge Protectors. 0-10V (010V) and Step (STEP) dimming functionality. Emergency Backup Battery (EM) and Emergency Battery Backup, Cold (EMC). Driver Available in A (350mA) drive current and B drive current (525 mA). Highly reliable. Suitable for dry, damp and wet locations. Compliant to worldwide safety regulations for lighting.

Testing Compliance

UL 1598 Issued: 2008/09/17 Ed:3 Rev:2012/10/17 UL Standard for Safety Luminaires CSA C22.2#250.0 Issued: 2008/09/17 Ed:3 Luminaires; General Instruction No.1 2010/01/11, General Instruction No. 2 2012/10/17.   (ANSI/UL 8750). UL Standard for Safety for Light Emitting Diode (LED) Equipment for use in Lighting Products - First Edition; Dated

Electrical System

Surge protection meets 10KV/5KA per ANSI/IEEEC62.41. Driver meets maximum harmonic distortion (THD) of 20% and is ROHS compliant.

Ambient Temperature

-40°C to +65°C (-40°F to + 149°F).

Manufacturing

Manufactured in beautiful Harbor City, CA. ARRA Compliant. NAFTA Compliant. Test and burn-in of 100% of all luminaries before shipment. No less than 8-years experience in manufacturing LED-based products. Note Specifications subject to change without notice. Actual performance may differ as a result of end-user environmen



5 Year Warranty
