| Electrical |
| Driver | Constant Current, 120V, 50/60 Hz, 700mA, 120V: 0.6A |
| THD | 6.8% at 120V, 12.4% at 277V |
| Power Factor | 99.5% at 120V, 93.6% at 277V |
| Photocell | 120-277V Twistlock photocell included. Photocell is compatible with 120-277V. |
| Surge Protection | 2kV |
| Compliance |
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| LED Characteristics |
| LEDs | Multi-chip, high-output, long-life LED |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 150 HPS |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Housing | Precision die-cast aluminum housing and arm |
| Effective Projected Area | EPA = 0.3 |
| Lens | High-impact, frosted polycarbonate lens |
| Reflector | High-reflectance white paint |
| Gaskets | High-temperature silicone |
| Finish | Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Mounts on pole |
| Recommended Mounting Height | 15 ft |
| Optical |
| BUG Rating | B1 U2 G1 |
