APPLICATION:
New narrow surface ceiling or wall mount wrap fixtures. Energy efficient fluorescent lighting fixture has linear sides prismatic acrylic diffuser provide sufficient up light and delivers diffuse and moderate down light in areas. Use for corridors and stairwells, utility closets and small office areas.
FEATURES:
- 100% acrylic, high-impact, injection molded prismatic basket diffuser with flat bottom and vertical sides.
- Diffuser choice prismatic acrylic or white opal acrylic.
- Die formed, cold-rolled, heavy gauge steel housing construction provides durability and strength.
- Models available with 1, 2, 3, 4 and 6 lamps.
- Lens are capable of being hinged from either side for easy cleaning and service.
- Screw latch system secures lens to base housing. (Wall mount)
- Finish is high-gloss baked white enamel over rust inhibiting phosphate coating for maximum corrosion resistance.
MOUNTING:
- Surface or stem mounting for individual installation.
- For ceiling or wall mounting.
- End to end row mounting option available.
- Compatible with most ceiling types.
LAMP:
- Standard T8, T5 and T5HO lamps are available.
- Pressure-lock lamp holders or easy twist lock lamp sockets.
- Lamp not included.
ELECTRICAL:
- High power factor instant start electronic ballast for T8 lamps are sound rate A, minimum starting temperature 0¡F (-18¡C), <10% THD and input voltage ranges of 120 to 277 volts comes as standard.
- High power factor programmed start electronic ballast for T5 and T5HO lamps are sound rate A, minimum starting temperature 0¡F (-18¡C), <10% THD and input voltage ranges of 120 to 277 volts comes as standard.
- Ballast disconnect plug provided as standard.
LISTING:
- UL/CUL listed and labeled.
- Suitable for damp locations.
- ARRA compliant (optional).
