| General | |
| Status | Active |
| Watts | 9W |
| Fluorescent Equivalent | 26W |
| Volts | 120V-277V |
| Ballast Type | Type A/B |
| Shape | PL |
| Base | G24d (2-Pin) |
| ANSI Base | G24d-2 |
| Finish | White |
| CCT (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Temperature | Warm White to Natural Light |
| CRI | 82 |
| Lumens | 1100L |
| Beam Spread | 120 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | PL 2-Pin |
| Lamp Type | PL 2-Pin |
| Operating Position | Universal |
| Technology | LED |
| Electrical | |
| Watts | 9W |
| Fluorescent Equivalent | 26W |
| Volts | 120V-277V |
| Ballasting Requirements | Ballast required (Type A) or Ballast Bypass (Type B) |
| Ballast Type | Type A/B |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 2700K/3000K/3500K/4000K/5000K |
| Temperature | Warm White to Natural Light |
| CRI | 82 |
| Lumens | 1100L |
| Beam Spread | 120 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| THD | 20% |
| Operating Position | Universal |
| Operating Temperature | -20C (-4F) to +45C (+113F) |
| Physical | |
| MOL | 6.76 |
| MOD | 2.36 |
| Shape | PL |
| Base | G24d (2-Pin) |
| ANSI Base | G24d-2 |
| Finish | White |
| Housing Color | White |
| Weight (lb.) | 0.4 |
| Additional Information | |
| Installation Notes | Suggested wattage equivalency = 26W CFL |
| Rated For Enclosed Fixture | No |
| Warranty | 5 Year Limited - 10 hr per day |
| Compliance | |
| Safety Listing | cULus - Certified; cULus - Classified; cULus - Listed |
| Location Rating | Damp |
| DLC Approved | No |
| NSF Approved | Yes |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| SDS Sheet | LED Lamp |
| Packaging | |
| Each UPC | 045923211485 |
| Each Quantity | 1 |
| Each Length (in.) | 2.44 |
| Each Width (in.) | 2.44 |
| Each Height (in.) | 6.89 |
| Each Weight (lb.) | 0.53 |
| Each Cube (CuFt.) | 0.0237 |
| Pack Type | Box |
| Inner UPC | 20045923211489 |
| Inner Quantity | 10 |
| Inner Length (in.) | 12.80 |
| Inner Width (in.) | 5.31 |
| Inner Height (in.) | 7.36 |
| Inner Weight (lb.) | 5.30 |
| Inner Cube (CuFt.) | 0.2895 |
| Case UPC | 10045923211482 |
| Case Quantity | 50 |
| Case Length (in.) | 27.36 |
| Case Width (in.) | 13.19 |
| Case Height (in.) | 8.27 |
| Case Weight (lb.) | 26.30 |
| Case Cube (CuFt.) | 1.7271 |
5 Year Limited - 10 hr per day
