| General | |
| Status | Active |
| Substitute | 65-830R1 |
| Fixture Type | Vapor Tight |
| Finish | White / Gray |
| Wattage | 20W |
| Lumen Output | 2065L-2249L |
| CCT (Kelvin) | 3000K/4000K/5000K |
| Temperature | Warm to Cool White |
| IP Rating | IP65 |
| Indoor or Outdoor Fixture | Indoor; Outdoor |
| Specifications | |
| Technology | LED |
| Wattage | 20W |
| Lumen Output | 2065L-2249L |
| CCT (Kelvin) | 3000K/4000K/5000K |
| Color Temperature | Warm to Cool White |
| CRI | 80 |
| Voltage | 120V-277V |
| Beam Angle | 115 |
| Rated Hours | 50000 |
| Operating Temperature | -40C (-40F) to +45C (+113F) |
| Dimmable | Yes-Dimmable |
| Dimming Note | 0-10V Dimming Only |
| Lens Material | Polycarbonate (PC) |
| Surge Protection | Built-in surge protection - 2KV |
| Weight (lb.) | 2.65 |
| IP Rating | IP65 |
| Material | Plastic |
| Dimensions | |
| Height (in.) | 3.11 |
| Width (in.) | 3.98 |
| Length (in.) | 23.62 |
| Compliance | |
| Safety Listing | cETLus - Listed |
| Location Rating | Wet |
| Energy Star | No |
| DLC Approved | Yes |
| DLC ID | PLIRMMY8BKKX |
| NSF Approved | Yes |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| Flicker Free | No |
| SDS Sheet | LED Fixture |
| Additional Information | |
| Warranty | 5 Year Limited - Fixtures |
| Packaging | |
| Each UPC | 045923650673 |
| Each Quantity | 1 |
| Each Length (in.) | 25.98 |
| Each Width (in.) | 6.89 |
| Each Height (in.) | 4.33 |
| Each Weight (lb.) | 2.94 |
| Each Cube (CuFt.) | 0.4485 |
| Pack Type | Box |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923650670 |
| Case Quantity | 6 |
| Case Length (in.) | 25.98 |
| Case Width (in.) | 13.78 |
| Case Height (in.) | 12.99 |
| Case Weight (lb.) | 17.64 |
| Case Cube (CuFt.) | 2.6912 |
5 Year Limited - Fixtures
