| Compliance |
| UL Listed | Suitable for wet locations in a covered ceiling |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Construction |
| IC Rated | Suitable for direct contact with insulation |
| Trim Component | This component can be ordered with New Construction housing in order to make a complete fixture.See here for New Construction Housing |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Lens | Nanostructure lens eliminates "hot spots", and helps provide smooth, uniform light and higher efficiency |
| Junction Box | Integral junction box with wiring capacity forMin 60°C supply conductorsEnd of Run |
| Housing | Specification-grade, die-cast aluminum construction |
| Installation | Torsion springs easily install into ceiling collar (remodeler) or rough-in (new construction) |
| Trim Ring | Silver powder coated die cast 1/2" trim ring |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Finish | Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color |
| Performance |
| Lifespan | 50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 50W MR16 |
| LED Characteristics |
| LED | High-output, long-life LED with 2-step binning and integrated driver technology |
| Color Consistency | 2-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Electrical |
| Driver | Constant Current, Class 2, 120VAC Only, 50/60Hz, 200mA, 0.07A |
| Dimming Driver | TRIAC and ELV (at 120V only).See dimmer compatibility guide here. |
| Optical |
| Optics | 20° beam spread with specular thermoplastic optics |
| Spacing Criteria | 0 to 180° (along): 0.3490 to 270° (across): 0.34diagonal: 0.36 |
