| Compliance |
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: PGLN0AV6 |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 400W Metal Halide |
| LED Characteristics |
| LEDs | Multip-chip, high-output, long-life LEDs |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -30°C (-22°F) |
| Maximum Ambient Temperature | 40°C (104°F) |
| Housing | Die-cast aluminum |
| Reflector | Aluminum alloy |
| Lens | Glass |
| Gaskets | High-temperature silicone gaskets |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Electrical |
| Driver | Constant Current, 120-277V, 50/60 Hz, 120V: 0.83A, 208V: 0.48A, 240V: 0.42A, 277V: 0.36A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 4.05% at 120V, 7.09% at 277V |
| Power Factor | 99.9% at 120V, 97.6% at 277V |
| Surge Protection | 4kV |
| Photocell | 120V Swivel photocell included. Photocell is only compatible with 120V. |
| Installation |
| Mounting | Surface mount |
| Optical |
| BUG Rating | B2 U5 G5 |
