| Compliance |
| UL Listed | Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground. |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| LED Characteristics |
| LEDs | Long-life, high-efficiency, surface-mount LEDs |
| Color Consistency | 5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017 |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Optical |
| BUG Rating | B1 U2 G1 |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Thermal Management | Cast aluminum Thermal Management system for optimal heat sinking. The BLED is designed for cool operation, maximum efficiency and long life by minimizing LED junction temperature. |
| Housing | Die-cast aluminum with extruded aluminum post |
| Lens | Frosted vandal resistant polycarbonate |
| Reflector | Vacuum-metalized polycarbonate |
| Gaskets | High-temperature silicone gaskets seal out moisture gaskets seal out moisture |
| Anchor Bolt | Anchor Bolt Dimension is available here. |
| Finish | Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Four (4) anchor bolts provided for concrete pad mounting. Internal base support has leveling screws. |
| Electrical |
| Driver | Constant Current, Class2, 100-277V, 50/60 Hz, 4kV Surge Protection, 700mA, 120V: 0.13A, 208V: 0.09A, 240V: 0.08A, 277V: 0.07A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 9.19% at 120V, 15.84% at 277V |
| Power Factor | 99.14% at 120V, 93.2% at 277V |
