2010TH HD Gen2
High Definition Underwater Lighting Excellence
The original Thru-Hull with the world's smallest hole cut-out for a thru hull light at only 1" is now brighter again - the 2010TH HD Gen2 model is 67% brighter than its predecessor by exploiting the next generation of High Definition LEDs from Cree.
With 7,000-fixture lumen brightness and a 1-inch (25mm) profile head make the 2010TH the ideal underwater light for transom mount applications.
Suitable for all hull types up to and over 65' (20m) using 2-6 lights with spacing of 3-5' (1-1.5m) - for metal hulls, choose the Delrin Isolation Sleeve accessory. Deutsch plug-and-play quick connectors make this light a quick fit. Maintenance is easy; just wipe away marine growth from its scratch resistant Tritonium™ glass lens. Three super bright LED color options.
- 1" Hole in Hull
- 67% Brighter than the Original 2010
- Equal to 250w HID/Metal Halide
- 12/24V DC (AC Upgrade Option)
- 40,000+ Hour Life
- Aluminium Bronze AB2
- Plug & Play
- No Breakable Parts
| Mounting Recommendations | 2010TH HD |
| Boat size | up to and over 65' (20m) |
| Transom / Hull spacing | 3-5' (1-1.5m) |
| Transom quantity | 2-6 |
| Maximum hull thickness | 31/2" (90mm) |
| Installation depth (to top of fixture) | 8-10in (200-250mm) |
| Technical | |
| Light output equivalent to | 250W HID Metal Halides |
| Fixture Lumens* (total light output from a finished fixture) | 7000 |
| Typical LED life expectancy | 40,000+ Hours |
| Minimum-Maximum operating voltage DC | 9-32V DC |
| Minimum-Maximum operating voltage AC | 90-270V AC |
| Current / Amp draw (DC) | 12V DC 5.8A24V DC 2.9A |
| Current / Amp draw (AC/optional) | 110V AC 50/60HZ 0.76A 240V AC 50/60HZ 0.35A |
| Approx. light penetration (avg. water quality) | 59' (18m) |
| Approx. Light penetration (perfect water quality) | up to 140' (45+m) |
| Driver type | External |
| Driver size (L x W x H) | TBA |
| Physical | |
| Diameter of fixture | 51/2" (140mm) |
| Profile (height) of fixture | 17/32" (30.8mm) |
| Total weight including electrical driver | 5.5lbs (2.5kgs) |
| Extension cable length (standard-hard wired to light) | 61/2' (2m) |
| Hole cut-out for cable entry | 1" (26mm) |
| Material | Aluminium Bronze AB2 |
| Lens | Tritonium™ Optical Lens |
