| Compliance |
| UL Listed | Suitable for wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| LED Characteristics |
| LEDs | Two (2) multi-chip, high-output, long-life LEDs |
| Color Consistency | 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377.2011. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Replaces 320W Metal Halide |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Thermal Management | Superior thermal management with external "Air-Flow" fins |
| Housing | Precision die-cast aluminum housing, lens frame |
| Arm | Die-cast aluminum with wiring access plate |
| Cutoff | Cutoff (7.5°) |
| Lens | Tempered glass |
| Reflector | Specular vacuum metallized polycarbonate |
| Gaskets | High-temperature silicone gaskets, including a wiring plug gasket, seal out moisture |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Electrical |
| Driver | Two drivers, Class 2, 1050mA, 120-277V, 50-60Hz, 0.8A, Power Factor 95% |
| THD | 6.04% at 120V, 10.38% at 277V |
| Power Factor | 99.5% at 120V, 93.4% at 277V |
| Surge Protection | 4kV |
| Installation |
| Mounting | Die-cast aluminum wall bracket with (5) 1/2" conduit openings with plugs. Two-piece bracket with tether for ease of installation and wiring. |
| Optical |
| BUG Rating | B1 U1 G1 |
