LLI Architectural Lighting LLI-N4.4W-67-SX63-XXXX LED Neon Square Profile
FEATURES & BENEFITS
Low luminosity surface mount LED Neon. Recommended applications: Outdoor/Indoor accent lighting, retail signage.
TECHNICAL INFORMATION
| WATTAGE | 4.4 W/ft |
| IP RATING | IP67 |
| BEND ORIENTATION | Side bending or Top bending |
| HOUSING MATERIAL | Silicone |
| LUMEN OUTPUT | Side bending: 191 lm/ft, 201 lm/ft Top bending: 273 lm/ft, 287 lm/ft |
| COLOR TEMPERATURE | 1800-3500K adjustable, 2700-5200K adjustable |
| INPUT VOLTAGE | 24VDC |
| CRI | 80+ |
| SEGMENT LENGTH | 2.46_ (side bending), not field-cuttable 1.97_ (top bending), not field-cuttable |
| MAXIMUM LENGTH | 32ft |
| MINIMUM BEND | 4.2_ diameter |
| CERTIFICATIONS | RoHS,ÊUL |
