Leviton RELAY-1TB Discontinued Product. GreenMAX Relay, Latching, 1-pole, basic, 30A 24-277, 347VAC 50/60Hz, Title 24 compliant, ASHRAE 90.1 compliant
Discontinued Product. GreenMAX Relay, Latching, 1-pole, basic, 30A 24-277, 347VAC 50/60Hz, Title 24 compliant, ASHRAE 90.1 compliant
- 25,000A Short Circuit Current Rating (SCCR) at 277VAC
- Rated at 30A General Fluorescent Ballast and 20A Incandescent
- All Models are Latching Relays with Manual Actuator
- Exclusive Dimming and Switching Relay Module for Daylight Harvesting
- Exclusive Dimming and Sensing Relay Module for Smart Metering
- Load Ratings: 24-277VAC, 20A Tungsten Halogen Incandescent,
- 24-277VAC, 30A Ballast, 347VAC, 20A Ballast, 120VAC 1/2 Hp Motor, 277VAC 1 Hp Motor, 240VAC 1Hp Motor, Wire Range: #14 - #6 AWG Copper, Torque 16 in.-lbs, 25,000A SCCR Rating at 277VAC
Product Features
Product Line: GreenMAX Product Type: Relay Module
