Leviton A5621-2W Antimicrobial Treated Decora Plus Rocker Switch, White
Amperage: 20 A
Dielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Operating Temperature: -40¡C to 65¡C
Storage Temperature: -40¼C to 65¼C
Cam: Thermoplastic
Contacts: Silver-Alloy
Ground Clips: Brass
Grounding Screw: Steel 8-32
Rocker: Antimicrobial Urea
Strap Material: Galvanized Steel
Terminal Screws: Brass 8-32
Amperage: 20 A
Dielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Operating Temperature: -40¡C to 65¡C
Storage Temperature: -40¼C to 65¼C
Cam: Thermoplastic
Contacts: Silver-Alloy
Ground Clips: Brass
Grounding Screw: Steel 8-32
Rocker: Antimicrobial Urea
Strap Material: Galvanized Steel
Terminal Screws: Brass 8-32
Antimicrobial Treated Decora Plus Rocker Switch, White
20 Amp, 120/277 Volt, Antimicrobial Treated Decora Plus Rocker, Single-Pole AC Quiet Switch, Commercial Spec Grade, Self Grounding, Back & Side Wired - WHITE
TOUGH: Made durable in order to withstand harsh chemical cleaning products, stringent washings, and UV lights with minimal wear and tear
CLEAN: Antimicrobial additive helps protect the device from the growth of odor-causing bacteria, mold, mildew, and fungi
Electrical Specifications
AC Horsepower Ratings: 1HP-120V 2HP-240V, 16A MaxAmperage: 20 A
Dielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Environmental Specifications
Flammability: Rated HB or better UL94Operating Temperature: -40¡C to 65¡C
Storage Temperature: -40¼C to 65¼C
Material Specifications
Body Material: Thermoplastic PolyesterCam: Thermoplastic
Contacts: Silver-Alloy
Ground Clips: Brass
Grounding Screw: Steel 8-32
Rocker: Antimicrobial Urea
Strap Material: Galvanized Steel
Terminal Screws: Brass 8-32
Mechanical Specifications
Product ID: Stamped on Strap Screw Terminal Torque: 14-18 in-lbs
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Brand: Decora Plus
Color: White
Device Type: Rocker Switch
Feature: Antimicrobial
Function: Single-Pole
Grade: Commercial Specification Grade
Voltage: 120/277 VAC
ISO 22196: Measurement of Antibacterial Activity on Plastics and Other Non-Porous Surfaces
JIS Z 2801:2000: Test for Antimicrobial Activity and Efficacy
NEMA: WD-1 & WD-6
NOM: NOM-ANCE
UL Standard: UL 20
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Product Features
Amperage: 20 ABrand: Decora Plus
Color: White
Device Type: Rocker Switch
Feature: Antimicrobial
Function: Single-Pole
Grade: Commercial Specification Grade
Voltage: 120/277 VAC
Standards and Certifications
CSA: C22.2ISO 22196: Measurement of Antibacterial Activity on Plastics and Other Non-Porous Surfaces
JIS Z 2801:2000: Test for Antimicrobial Activity and Efficacy
NEMA: WD-1 & WD-6
NOM: NOM-ANCE
UL Standard: UL 20
Warranty
Warranty: 10-Year LimitedElectrical Specifications
AC Horsepower Ratings: 1HP-120V 2HP-240V, 16A MaxAmperage: 20 A
Dielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Environmental Specifications
Flammability: Rated HB or better UL94Operating Temperature: -40¡C to 65¡C
Storage Temperature: -40¼C to 65¼C
Material Specifications
Body Material: Thermoplastic PolyesterCam: Thermoplastic
Contacts: Silver-Alloy
Ground Clips: Brass
Grounding Screw: Steel 8-32
Rocker: Antimicrobial Urea
Strap Material: Galvanized Steel
Terminal Screws: Brass 8-32
Mechanical Specifications
Product ID: Stamped on Strap Screw Terminal Torque: 14-18 in-lbs
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Brand: Decora Plus
Color: White
Device Type: Rocker Switch
Feature: Antimicrobial
Function: Single-Pole
Grade: Commercial Specification Grade
Voltage: 120/277 VAC
ISO 22196: Measurement of Antibacterial Activity on Plastics and Other Non-Porous Surfaces
JIS Z 2801:2000: Test for Antimicrobial Activity and Efficacy
NEMA: WD-1 & WD-6
NOM: NOM-ANCE
UL Standard: UL 20
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Product Features
Amperage: 20 ABrand: Decora Plus
Color: White
Device Type: Rocker Switch
Feature: Antimicrobial
Function: Single-Pole
Grade: Commercial Specification Grade
Voltage: 120/277 VAC
Standards and Certifications
CSA: C22.2ISO 22196: Measurement of Antibacterial Activity on Plastics and Other Non-Porous Surfaces
JIS Z 2801:2000: Test for Antimicrobial Activity and Efficacy
NEMA: WD-1 & WD-6
NOM: NOM-ANCE
UL Standard: UL 20
Warranty
Warranty: 10-Year Limited
