Leviton 90W04-S 15 Amp, 125 Volt, NEMA 1-15, 2P, 2W, Straight Blade Single Outlet, Industrial Grade, Non-Grounding, Wetguard - YELLOW

Leviton 90W04-S 15 Amp, 125 Volt, NEMA 1-15, 2P, 2W, Straight Blade Single Outlet, Industrial Grade, Non-Grounding, Wetguard - YELLOW

Leviton

(No reviews yet) Write a Review
SKU:
LEVITON-90W04-S
Weight:
0.00 LBS
Call for price
Leviton 90W04-S 15 Amp, 125 Volt, NEMA 1-15, 2P, 2W, Straight Blade Single Outlet, Industrial Grade, Non-Grounding, Wetguard - YELLOW

15 Amp, 125 Volt, NEMA 1-15, 2P, 2W, Straight Blade Single Outlet, Industrial Grade, Non-Grounding, Wetguard - YELLOW



Electrical Specifications
Amperage: 15 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 125 VAC
Wire: 2

Environmental Specifications
Enclosure Rating: NEMA 4, 4X, 12 IEC IP66
Environment: Wet
Flammability: Rated V-2 per UL 94 (wiring module)
Operating Temperature: -40¡C to 60¡C

Material Specifications
Blades/Contacts, Terminal Clamps: Electroless Nickel-coated Brass
Cover Gasket: Santoprene TPV
Cover/Lid: Valox PBT
Mounting & Assembly Screws: Stainless steel, non-magnetic
Terminal Screws: Electroless Nickel-coated Brass
Torsion Spring Mechanism (Flip Lids): Stainless Steel
Wiring Module: Nylon
Wiring Module Mounting Cup: Valox PBT

Mechanical Specifications
Product ID: Ratings and NEMA I.D. permanently marked on device
Terminal Accom.: #18 AWG to # 10 AWG

Product Features
Brand: Wetguard
Color: Yellow
Device Type: Straight Blade Outlet
NEMA: 1-15R

Standards and Certifications
ANSI: C-73
CSA: C22.2 No. 42
NEMA: WD-6
NOM: 057
UL: 498
Warranty: Limited Lifetime Warranty


Electrical Specifications
Amperage: 15 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 125 VAC
Wire: 2

Environmental Specifications
Enclosure Rating: NEMA 4, 4X, 12 IEC IP66
Environment: Wet
Flammability: Rated V-2 per UL 94 (wiring module)
Operating Temperature: -40¡C to 60¡C

Material Specifications
Blades/Contacts, Terminal Clamps: Electroless Nickel-coated Brass
Cover Gasket: Santoprene TPV
Cover/Lid: Valox PBT
Mounting & Assembly Screws: Stainless steel, non-magnetic
Terminal Screws: Electroless Nickel-coated Brass
Torsion Spring Mechanism (Flip Lids): Stainless Steel
Wiring Module: Nylon
Wiring Module Mounting Cup: Valox PBT

Mechanical Specifications
Product ID: Ratings and NEMA I.D. permanently marked on device
Terminal Accom.: #18 AWG to # 10 AWG

Product Features
Brand: Wetguard
Color: Yellow
Device Type: Straight Blade Outlet
NEMA: 1-15R

Standards and Certifications
ANSI: C-73
CSA: C22.2 No. 42
NEMA: WD-6
NOM: 057
UL: 498
Warranty: Limited Lifetime Warranty
