Leviton 15W18 Watertight Straight Blade Connector
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Grounding
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 347 VAC
Wire: 3
Flammability: Rated V-2 per UL 94
IP Rating: IP66, IP67, IP69K
Operating Temperature: -40¡C to 60¡C
Blades/Contacts: Electroless Nickel-coated Brass
Body Interior: Nylon
Body Material: Santoprene TPV
Bushing: Santoprene TPV
Compression Nut, Strain Relief: Nylon
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Grounding
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 347 VAC
Wire: 3
Flammability: Rated V-2 per UL 94
IP Rating: IP66, IP67, IP69K
Operating Temperature: -40¡C to 60¡C
Blades/Contacts: Electroless Nickel-coated Brass
Body Interior: Nylon
Body Material: Santoprene TPV
Bushing: Santoprene TPV
Compression Nut, Strain Relief: Nylon
Watertight Straight Blade Connector
20 Amp, 347 Volt, NEMA 24-20R, 2P, 3W, Connector, Straight Blade, Industrial Grade, Grounding, Wetguard - YELLOW
Electrical Specifications
Amperage: 20 ACurrent Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Grounding
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 347 VAC
Wire: 3
Environmental Specifications
Environment: WetFlammability: Rated V-2 per UL 94
IP Rating: IP66, IP67, IP69K
Operating Temperature: -40¡C to 60¡C
Material Specifications
Assembly Screws: Stainless Steel, Non-MagneticBlades/Contacts: Electroless Nickel-coated Brass
Body Interior: Nylon
Body Material: Santoprene TPV
Bushing: Santoprene TPV
Compression Nut, Strain Relief: Nylon
Terminal Screws: Electroless Nickel-coated Brass
Wire Module: Nylon
Product ID: Ratings and NEMA I.D. permanently marked on device
Terminal Accom.: #16 to #10
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Color: Yellow
Device Type: Straight Blade Connector
NEMA: 24-20R
CSA C22.2 No. 42: File LR-406
NEMA: WD-6
NOM: 057
UL: 498
UL Fed Spec WC-596: File E13393
Warranty: Limited Lifetime Warranty
Wire Module: Nylon
Mechanical Specifications
Cord Grip Range (in): .375-.875Product ID: Ratings and NEMA I.D. permanently marked on device
Terminal Accom.: #16 to #10
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Product Features
Brand: WetguardColor: Yellow
Device Type: Straight Blade Connector
NEMA: 24-20R
Standards and Certifications
ANSI: C-73CSA C22.2 No. 42: File LR-406
NEMA: WD-6
NOM: 057
UL: 498
UL Fed Spec WC-596: File E13393
Warranty: Limited Lifetime Warranty
