Leviton 1288-W Maintained Contact Toggle Switch
Dielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Operating Temperature: -40¡C to 65¡C
Color: White
Contact Material: Silver Alloy
Cover Material: Thermoplastic
Ground Clips: Brass
Grounding Screw: Brass 8-32
Strap Material: Steel
Terminal Screws: Brass 8-32
Toggle: Polycarbonate
Dielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Operating Temperature: -40¡C to 65¡C
Color: White
Contact Material: Silver Alloy
Cover Material: Thermoplastic
Ground Clips: Brass
Grounding Screw: Brass 8-32
Strap Material: Steel
Terminal Screws: Brass 8-32
Toggle: Polycarbonate
Maintained Contact Toggle Switch
30 Amp, 120/277 Volt, Toggle Double-Throw Ctr-OFF Maintained Contact Double-Pole AC Quiet Switch, Industrial Grade, Grounding, Back & Side Wired - WHITE
AC Horsepower Ratings
HP Rating: 2HP-120V 2HP-240V-277VElectrical Specifications
Amperage: 30 ADielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Environmental Specifications
Flammability: Rated V-2 per UL 94Operating Temperature: -40¡C to 65¡C
Material Specifications
Base Material: ThermoplasticColor: White
Contact Material: Silver Alloy
Cover Material: Thermoplastic
Ground Clips: Brass
Grounding Screw: Brass 8-32
Strap Material: Steel
Terminal Screws: Brass 8-32
Toggle: Polycarbonate
Mechanical Specifications
Product ID: Ratings are permanently marked on device Screw Terminal Torque: 14-18 in-lbs
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Color: White
Device Type: Toggle Switch
Feature: Maintained Contact CTR OFF
Function: Double-Pole Double-Throw
Grade: Extra Heavy-Duty Industrial Specification Grade
Grounding: Self-Grounding
HP Rating: 2HP-120V 2HP-240V-277V
Strap Material: Steel
Voltage: 120/277 VAC
CSA C22.2 No. 111: File #152105
NEMA: WD-1 & WD-6
NOM: 057
RoHS: Compliant
UL Fed Spec WS896E: File #E7458
UL Standard: UL 20
Warranty: 10-Year Limited
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Product Features
Body Material: ThermoplasticColor: White
Device Type: Toggle Switch
Feature: Maintained Contact CTR OFF
Function: Double-Pole Double-Throw
Grade: Extra Heavy-Duty Industrial Specification Grade
Grounding: Self-Grounding
HP Rating: 2HP-120V 2HP-240V-277V
Strap Material: Steel
Voltage: 120/277 VAC
Standards and Certifications
ANSI: C-73CSA C22.2 No. 111: File #152105
NEMA: WD-1 & WD-6
NOM: 057
RoHS: Compliant
UL Fed Spec WS896E: File #E7458
UL Standard: UL 20
Warranty: 10-Year Limited
AC Horsepower Ratings
HP Rating: 2HP-120V 2HP-240V-277VElectrical Specifications
Amperage: 30 ADielectric Voltage: Withstands 1500V for 1 minute
Endurance: 50,000 cycles minimum
Grounding: Self-Grounding
Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
Temperature Rise: Maximum 30 degrees C rise
Voltage: 120/277 VAC
Environmental Specifications
Flammability: Rated V-2 per UL 94Operating Temperature: -40¡C to 65¡C
Material Specifications
Base Material: ThermoplasticColor: White
Contact Material: Silver Alloy
Cover Material: Thermoplastic
Ground Clips: Brass
Grounding Screw: Brass 8-32
Strap Material: Steel
Terminal Screws: Brass 8-32
Toggle: Polycarbonate
Mechanical Specifications
Product ID: Ratings are permanently marked on device Screw Terminal Torque: 14-18 in-lbs
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Color: White
Device Type: Toggle Switch
Feature: Maintained Contact CTR OFF
Function: Double-Pole Double-Throw
Grade: Extra Heavy-Duty Industrial Specification Grade
Grounding: Self-Grounding
HP Rating: 2HP-120V 2HP-240V-277V
Strap Material: Steel
Voltage: 120/277 VAC
CSA C22.2 No. 111: File #152105
NEMA: WD-1 & WD-6
NOM: 057
RoHS: Compliant
UL Fed Spec WS896E: File #E7458
UL Standard: UL 20
Warranty: 10-Year Limited
Terminal Accom.: 14-#10 AWG back wired; #14-#12 AWG side wired
Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
Termination: Back or Side Wire
Product Features
Body Material: ThermoplasticColor: White
Device Type: Toggle Switch
Feature: Maintained Contact CTR OFF
Function: Double-Pole Double-Throw
Grade: Extra Heavy-Duty Industrial Specification Grade
Grounding: Self-Grounding
HP Rating: 2HP-120V 2HP-240V-277V
Strap Material: Steel
Voltage: 120/277 VAC
Standards and Certifications
ANSI: C-73CSA C22.2 No. 111: File #152105
NEMA: WD-1 & WD-6
NOM: 057
RoHS: Compliant
UL Fed Spec WS896E: File #E7458
UL Standard: UL 20
Warranty: 10-Year Limited
