| Field Adjustability |
| Field Adjustable | Field Adjustable Light Output:
25W/20W/15W (factory default 25W)Color temperature selectable by 5000K, 4000K and 3500K (factory default 4000K) |
| Compliance |
| UL Listed | Suitable for damp locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: S-TXS13W (Direct Linear Ambient Luminaires) |
| Electrical |
| Driver | Constant Current, Class 2, Class P, 120-277V, 50/60 Hz25W: 120V: 0.21A, 208V: 0.12A, 240V: 0.11A, 277V: 0.1A20W: 120V: 0.17A, 208V: 0.1A, 240V: 0.09A, 277V: 0.08A15W: 120V: 0.13A, 208V: 0.08A, 240V: 0.07A, 277V: 0.06A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 6.6% at 120V, 14.51% at 277V |
| Power Factor | 99.44% at 120V, 94.47% at 277V |
| Surge Protection | L-N: 1KVL/N-PG: 2KV |
| Battery Backup | Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V. |
| Battery Backup Light Loss Factor | 25W: 0.1520W: 0.1814W: 0.25 |
| Performance |
| Lifespan | 50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | 25W: Replaces up to (1) F32T8 or (3) F17T820W: Replaces up to (1) F32T8 or (2) F17T815W: Replaces up to (1) F32T8 or (2) F17T8 |
| LED Characteristics |
| LEDs | Long-life, high-efficiency, surface-mount LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Construction |
| Cold Weather Starting | The minimum starting temperature is 0°C (32°F) |
| Maximum Ambient Temperature | Suitable for use in up to 50°C (122°F) |
| Housing | Color coated steel sheets |
| Lens | Polycarbonate lens |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Surface mount. Can be mounted with v-hooks (ordered separately). |
