Key Features:
Controls Ready
Easily add controls anytime without the need for additional wiring.
Pre-Installed 10ft Cord
10ft power and dimming cord out of the box makes installation and servicing easy.
Multiple Mounting Option
Multiple ways to mount; eyebolt (included), pipe adapter, hook or yoke mount (optional). Pipe adapter for pendant mounting (easily connects directly to conduit via 3/4in threaded pipe), includes hook mount which quickly accommodates chain length, while the adjustable yoke mount is ideal for surface mount applications.
Highlights:
- Round high bay designed with performance and value in mind
- Controls Ready makes adding controls quick and easy. Includes screw-in receptacle for Standalone sensors or Networked Lighting Controls
- Includes extended length 10ft power and dimming cord and hook for easy installation
- Reflectors and mounting accessories available
- PowerSet feature allows for multiple lumen stops out of the box
- FieldCCeT features provides multiple color temperature settings in one fixture
Certifications:
- UL Certified for US & Canada
- RoHS Compliant
- FCC Compliant
- ICES-005 Compliant
- IP65 Rated
- DesignLights Consortium Premium Qualified - meets the requirements for the highest DLC qualification for efficacy and lumen maintenance
Thermal:
- -40Deg. F to 122Deg. F (-40Deg. C to 50Deg. C) ambient operating temperature
- Ambient operating temperature with sensor
Construction:
- Matte black or white powder coated, forged aluminum
- Impact-resistant polycarbonate lens
- 10ft power and dimming cord
- Hook included
Applications:
- Warehouses
- Manufacturing Plants
- Distribution Centers
- Grocery Stores
- Gymnasiums
- Indoor Recreational Facilities
- Cold Storage
- Big Box Retail
- Service Repair Centers
Specification:
- Voltage: 120-277VAC
- Lumens (lm): 22,500 lm
- Wattage: 150W
- Efficacy (lm/W): 150 lm/W
- CCT (K): 5000K
- CRI: 80+
- Dimming: 0-10
- Replacement for: Up to 400W HID
- DLC Version: DLC Premium
- T20 Status: Exempt
- IP Rating: IP65
- Wet/Damp/Dry Location: Wet
- Dimensions (L x W x H): Ø: 11 3/16in (284mm), H: 5 11/16in (144mm)
- Housing Color: Matte Black
- Lens Material New: Polycarbonate (PC)
- Ambient Temp Range: -40F to 122F (-40C to 50C)
5 Years
