| Compliance |
| UL Listed | Suitable for wet locations. Suitable for mounting within 4 ft of the ground. |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| Trade Agreements Act Compliant | This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act |
| LED Characteristics |
| LEDs | Multi-chip, high-output, long-life LEDs |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | 75W PAR30 |
| Construction |
| Thermal Management | Superior heat sinking with external Air-Flow fins |
| Housing | Die-cast aluminum housing, lens frame and mounting plate |
| Reflector | Semi-specular, vacuum-metalized polycarbonate |
| Lens | Microprismatic diffusion lens for smooth and even light distribution |
| Gaskets | High-temperature silicone gaskets |
| Finish | Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Optical |
| NEMA Type | NEMA Beam Spread of 6H x 6V |
| Installation |
| Mounting | Heavy-duty mounting arm with "O" ring seal and stainless steel screws |
| Electrical |
| Driver | Innovative integrated driver technology with 120V TRIAC and ELV dimming |
| THD | 10.9% at 120V |
| Power Factor | 99.1% at 120V |
