| Field Adjustability |
| Field Adjustable | Field Adjustable Light Output:
100W/80W/60W (factory default: 100W)Color Temperature Selectable:3000K, 4000K and 5000K (factory default:4000K) |
| Compliance |
| UL Listed | Suitable for wet locations. Suitable for mounting within 4ft (1.2m) of the ground. |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| Trade Agreements Act Compliant | This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: S-8JX8VS |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | 100W: Replaces up to 400W Metal Halide (MH) or 310W High Pressure Sodium (HPS)
80W: Replaces up to 350W Metal Halide (MH) or 250W High Pressure Sodium (HPS)
60W: Replaces up to 250W Metal Halide (MH) or 200W High Pressure Sodium (HPS) |
| Electrical |
| Driver | Constant Current, Class 1, 480V, 50/60 Hz:
100W: 480V: 0.21A
80W: 480V: 0.17A
60W: 480V: 0.13A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 13.72% at 480V |
| Power Factor | 93.4% at 120V, 0% at 277V |
| 7-Pin Receptacle with Shorting Cap | ANSI C136.41 7-pin receptacle, compatible with wireless control systems |
| Surge Protection | 6kV |
| Construction |
| IES Classification | The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area. |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Lens | Polycarbonate lens |
| Housing | Die-cast aluminum |
| Effective Projected Area | 1 Fixture: 0.32 Fixtures: 0.73 Fixtures: 1.24 Fixtures: 1.2 |
| Finish | Formulated for high durability and long-lasting color |
| Gaskets | High-temperature silicone gaskets |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Installation |
| Mounting | Adjustable universal pole mount (standard). Slipfitter and wall mount accessory available. |
| Optical |
| BUG Rating | Type 3100W: B2 U0 G280W: B2 U0 G260W: B2 U0 G1 |
