- 250-400w Typical HID Replacement*
- 9,926 Delivered Lumens***
- 100,000+ Hours Rated LED Life
- DesignLights Consortium® Qualified Retrofit Kits****
- 50-90% Energy Reduction Over HID Lighting
- Precision Engineered & Made In USA
- ETL Certified, UL & CSA Standards, ROHS Compliant
- 5-Year Light Engine Warranty
Note: Additional wattages and configurations available upon request. Specifications are subject to change without notice.
*Considered to be a typical HID equivalent. Specific HID wattage equivalents will depend on things like (but not limited to) environmental and application characteristics, distribution type(s) and design criteria.
**Considered a nominal value of the LED light engine as specified by the LED chip manufacturer. Fixture efficacy and lumen output will depend on things like (but not limited to) housing design, lens clarity, environmental characteristics, color temperature and design criteria.
***Considered the typical delivered lumens of the LED light engine. Specific lumens for an application will depend on things like (but not limited to) fixture size and geometry, environmental characteristics and color temperature.
****This designation applies to the Noribachi DLC QPLretrofit kit.
Applications: Ideal for exterior environments and large outdoor areas such as streets, highways, roadways, walkways and alleys.
Housing Construction: Rugged, die-cast, traditional, cobrahead, aluminum housing with impact-resistant, tempered glass lens, durable silicone gasket and tool-less entry for easy relamping, servicing and weatherproofing.
Finish: Durable, multi-layer, polyester powdercoat with exceptional resistance against abrasion, corrosion, acid salt spray and unltraviolet rays. Available in a variety of colors such as dark bronze, black, white, light gray, dark green and natural aluminum.
Optics: Available in Type V wide and narrow lighting photometric distributions that provide superior uniformity, excellent vertical light distribution and reduced wasted spill light onto neighboring properties. Other photometric distributions availbale upon request.
Electrical:
- AC Input: 100-277v, 347v or 480v
- EMI Filter: 47CFR, Part 2, Part 15
- Power Factor: >0.9
- Surge Protection: IEC/EN 61000-4-5 EMC
- Operating Temperature: -30°C to +60°C
- Shock & Vibration Resistant
- Turns On Instantly
- High 75+ CRI & Color Enhancement
Energy Control Options:
- Motion Detection
- Photo Sensors
- Lighting Management
