USE OF PRODUCT
The intended use of this product is for decorative wall mount, building accents, pedestrian walkways, public access areas, or to accent landscape areas.



HOUSING
Die Cast gasketed aluminum housing with integral heat sinking and driver compartment. Nickel-Plated Stainless Steel Hardware.



FINISH
Matt-finished, architectural bronze powdercoat over a precise chromate conversion coating. Available in standard dark polyester bronze or consult factory for made to order architectural finishes.



OPTICS
Polycarbonate Opal Lens is sealed by a one-piece silicon gasket which prohibits entrance of outside contamination. Type IV Distribution.



LED
High output LEDs offer a minimum estimated operating life of 50,000 hours in 3000K, 4000K, or 5000K (standard) with CRI>80.



DRIVER
Durable and long lasting LED driver operates at 120-277V and boasts a 90% power factor at 50 to 60 Hz with 0-10V Dimming Constant Current. Driver protections includes: Output open load, over-current and short-circuit, and over-temperature with auto recovery. -40¼C Min Temp. 50¼C Max Temp.

MOUNTING
Surface mount.



LISTINGS/COMPLIANCE
¥ CEC Compliant emergency driver

¥ CSA -Suitable for wet location.
¥ ANSI/UL 1598
¥ 8750 IP65 Sealed LED compartment.
