Lithonia Lighting 47882 Contour¨ Soft Square KAD

Ideal for car lots, street lighting or parking areas. Construction Rugged, die-cast, soft corner aluminum housing with 0.12" nominal wall thickness. Die-cast doorframe has impact-resistant, tempered, glass lens that is fully gasketed with one piece tubular silicone. Finish: Standard finish is dark bronze (DDB)polyester powder finish, with other architectural colors available. Optics Anodized, aluminumÊreflectors: IES full cutoff distributions R2(asymmetric), R3 (asymmetric), R4 (forward throw), and R5S (square) are interchangeable. High-performance anodized, segmented aluminum reflectors: IES full cutoff distributions SR2 (asymmetric), SR3 (asymmetric), and SR4SC (forward throw, sharp cutoff). Segmented reflectors attach with tool-less fasteners and are rotatable and interchangeable. Nighttime Friendlyª - Square die-cast housing, flat lens, 400W max. House side shield available in R2, R3, R4, SR2 and SR3. Electrical Ballast: high reactance, high power factor for 70 - 150W. Constant wattage autotransformer for 175 - 400W. Metal halide 150W and below are standard with pulse-start ignitor technology; super CWA pulse-start ballast required for 200W, 320W and 350W (SCWA option). Ballast isÊ100% factory-tested. Socket: porcelain, horizontally oriented medium base socket for 70 - 150W and mogul base socket for 175W and above, with copper alloy, nickel-plated screw shell center contact. UL listed 1500W, 600V. Installation Mounting: Extruded 4" aluminum arm for square pole mounting, shipped in fixture carton as standard. Optional mountings available.
