| Compliance |
| UL Marine Listed | Marine Listed Outside Type (Saltwater) |
| UL 94 | 5VA flame classification |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| NEMA Rating | 4X, protected against corrosion |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.DLC Product Code: PUMP3BT5DLC Product Code: PV878XAQ |
| Construction |
| Length | 2 ft |
| Reflector | Specular polycarbonate |
| Housing | IK09 impact-resistant polycarbonate with 5VA flame rating*1/2" openings for conduit and bushing/cord entry*Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals. |
| Lens | Textured, diffuse polycarbonate lens for low glare and maximum protection |
| Gaskets | EVA |
| Cold Weather Starting | The minimum starting temperature is -30°C (-22°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Finish | Formulated for high durability and long-lasting color |
| Installation |
| Mounting | Quick-mount, surface, stainless steel spring clips and V-Hook with bracket screws are supplied. 3 additional mounting accessory kits available. |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Electrical |
| Driver | Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.16A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A |
| THD | 3.61% at 120V, 6.33% at 277V |
| Power Factor | 99.3% at 120V, 88.6% at 277V |
| Surge Protection | 4kV |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
