Key Features:
Controls Ready
Easily add controls anytime without the need for additional wiring.
Installation Made Easy
Four 1/2in Knockouts (one each side); plus one 3/4ft on the top; one 12mm pre-drill hole for battery backup test button. Hinged door and can be mounted with or without Junction Box.
Vandal Resistant Sensor
Vandal resistant sensor cover accessory available to prevent tamporing with controls.
Highlights:
- Architectural modern style garage and canopy
- Controls Ready makes adding controls quick and easy. Includes screw-in receptacle for Standalone sensors or Networked Lighting Controls
- Hinged junction box makes installation and maintenance easier
- Four 1/2in Knockouts (one on each side) plus one 3/4ft on the top; one 12mm pre-drill hole for battery backup test button
- PowerSet feature allows for multiple lumen stops out of the box
- FieldCCeT features provides multiple color temperature settings in one fixture
Certifications:
- UL Certified for US & Canada
- RoHS Compliant
- FCC Compliant
- ICES-005 Compliant
- Wet Location
- IP65 Rated
- IK08
- DesignLights Consortium Premium Qualified - meets the requirements for the highest DLC qualification for efficacy and lumen maintenance
Thermal:
- -40Deg. F to 113Deg. F (-40Deg. C to 45Deg. C) ambient operating temperature
- Ambient operating temperature with sensor
Construction:
- White powder coated die-cast aluminum housing
- Impact-resistant polycarbonate lens
Applications:
- Canopies
- Parking Garages
- Stairwells
Specification:
- Voltage: 120-347VAC
- Lumens (lm): 6,300 / 4,900 / 3,500 lm
- Wattage: 45/35/25W
- Efficacy (lm/W): 140 lm/W
- CCT (K): 4000K / 5000K
- CRI: 80+
- Dimming: Yes
- Replacement for: Up to 100W HID
- DLC Version: DLC Premium
- T20 Status: Exempt
- IP Rating: IP65
- Wet/Damp/Dry Location: Wet
- RoHS Compliant: Yes
- FCC Compliant New: Yes
- ETL/cETLus Listed: Yes
- cULus Listed: Yes
- Dimensions (L x W x H): 9.6*9.6*4in (243*243*102mm)
- Housing Color: White
- Lens Material New: Polycarbonate (PC)
- Ambient Temp Range: -40F to 113F (-40C to 45C)
- Driver Surge Protection (kV) new: L/N-PE: 4kV, L-N: 4kV
- Auxiliary Output: Yes (12V)
- General Warranty: 5 Years
5 Years
