| Voltage | 120-277VAC |
| Lumens (lm) | 21,000 lm / 18,200 lm / 15,400 lm / 12,600 lm |
| Wattage | 150W / 130W / 110W / 90W |
| Efficacy (lm/W) | 140 lm/W |
| CCT | 4000 |
| CRI | 80+ |
| Dimming | 0-10 |
| Replacement For/Equivalent | 6 lamp 4ft 32W T8 / 4 lamp 4ft 54W T5 / 400W HID (150W LHC1) 4 lamp 4ft 32W T8 / 250W HID (90W LHC1) |
| DLC Version | DLC Premium |
| T20 Status | Exempt |
| IP Rating | IP20 |
| Wet/Damp/Dry Location | Damp |
| IK Rating | 6 |
| Dimensions (L x W x H) | L: 14 3/16" (360 mm), W: 11" (280 mm), H: 1 7/8" (48 mm) |
| Housing Color | White |
| Lens Material | Polycarbonate (PC) |
| Operating Temp Range (°F/°C) | Without Motion Sensor: -40F to 122F (-40C to 50C), With Motion Sensor: -22F to 122F (-30C to 50C) |
| Driver Surge Protection (kV) | L/N-PE: 6kV, L-N: 6kV |
| Auxiliary Output | 12V |
| Brand | EiKO |
LHC1 Linear High Bay Compact, PowerSet 150/130/110/90W, 4000K, 120-277V, 0-10V Dimming | LHC1-PS150-40-U | 13141 | EiKO
EiKO
$107.69
(No reviews yet)
Write a Review
Write a Review
EiKO
LHC1 Linear High Bay Compact, PowerSet 150/130/110/90W, 4000K, 120-277V, 0-10V Dimming | LHC1-PS150-40-U | 13141 | EiKO
- SKU:
- LHC1-PS150-40-U
- UPC:
- 031293131416
- Availability:
- Usually ships within 1 week
- Weight:
- 5.61 LBS
- Minimum Purchase:
- 1 unit
- Shipping:
- Calculated at Checkout
- Spec Sheet:
- Spec Sheet
- Instruction Sheet:
- Instruction Sheet
- Sell Sheet:
- Sell Sheet
- Lens Material:
- Polycarbonate (PC)
- Lumens:
- 21,000 lm / 18,200 lm / 15,400 lm / 12,600 lm
- Efficacy:
- 140 lm/W
- Max Wattage:
- 150W / 130W / 110W / 90W
- CCT:
- 4000
- CRI:
- 80+
- Rated Life:
- 50,000
- System Wattage:
- 149.5W
- Input Voltage:
- 120-277VAC
- Output Voltage:
- 180-260Vdc
- THD:
- 15%
- Inrush Current:
- <80A
- Dimmable:
- 0-10
- Order Code:
- 13141
