Key Features:
Lamp-For-Lamp Replacement
Hassle-free install with a lamp-for-lamp replacement.
Shatter Resistant & NSF
Polycarbonate lamps meet the requirements for NSF; aiding as a component to a NSF lighting system and reduces breakage.
Wide Range of Compatibility
Compatible with a wide range of ballasts (instant-start, programmed start, programmed dimmable, and emergency.
Wider Beam, More Light
Wide illumination angle provides 330Deg. of light distribution.
Highlights:
- LED T8 Type A plug and play replacement lamps directly replace T8 fluorescent lamps without having to change a ballast
- Functions on most electronic T8 ballast (instant & programmed) and battery backup
- Instantaneous full light output upon power-up
- Wide illumination angle provides up to 330Deg. of light distribution
- Glass material for better light transmission (glass models)
- Plastic (polycarbonate) material for durability and reduced breakage (plastic models)
- Frosted lens reduces visual glare
- Plastic models meet the requirements for NSF; aiding as a component to a NSF lighting system
Certifications:
- UL Certified for US & Canada
- FCC Compliant
- RoHS Compliant
- ICES-005 Compliant
- Damp Location
- DesignLights Consortium Qualified - meets DLC requirements for efficacy and lumen maintenance
Thermal:
- -4Deg. F to 113Deg. F (-20Deg. C to 45Deg. C) operating temperature
- Not recommended for air-tight fixtures
Construction:
- U-bend models available in 1 5/8in and 6in leg spacing
- Frosted glass lens provides optimal heat dissipation (glass models)
- polycarbonate lens for durability (plastic models)
- G13 base
Applications:
- Office
- Hospital
- Classroom
- Hotel
- Retail
- Warehouse
- Stairwell
- Hallway
- Production
- Gym
- Campus
Specification:
- Voltage: 120-277VAC
- Lumens (lm): 1,600 lm
- Wattage: 8.9W
- Efficacy (lm/W): 179 lm/W
- Lamp Base Type: G13
- Nominal Size: 4ft
- CCT (K): 4000K
- CRI: 80+
- RATED LIFE: 50,000
- Dimming: Triac
- Housing Material: Plastic
- T20 Status: Exempt
- NSF Rating: Yes
- IP Rating: IP20
- Wet/Damp/Dry Location: Damp
- RoHS Compliant: Yes
- cULus Listed: Yes
- Ambient Temp Range: -4F to 113F (-20C to 45C)
- General Warranty: 5 Years
5 Years
