65-556 - 80/100/120W LED Full Cutoff Wall Pack 3K/4K/5K CCT Selectable 120-347V IP65 - Satco/Nuvo

Satco

(No reviews yet) Write a Review

SKU:: 65-556
UPC:: 45923434167
Weight:: 9.74 LBS
Wattage:: 80/100/120W Field Selectable
Voltage:: 120-347V
Lumens:: 12107-17789
Color Temperature:: 3000K/4000K/5000K Field Selectable
CRI:: 80
Dimmable:: Yes
Mounting Type:: Wall Mount
Housing Material:: Die-Cast Aluminum
Finish:: Bronze
IP Rating:: IP65
Wet/Damp Rating:: Wet Location
Certification:: cULus, DLC Premium (S-CW1MVQ)
Rated Hours:: 50000
Beam Angle:: 106
Distribution Type:: Type II
Photocell Included:: Yes - Bypassable
Dark Sky Compliant:: Yes (Full Cutoff, B2-U0-G2 BUG Rating)
Solar Powered:: false
Integrated Led:: true

Wattage:

80/100/120W Field Selectable

Voltage:

120-347V

Lumens:

12107-17789

Color Temperature:

3000K/4000K/5000K Field Selectable

CRI:

Dimmable:

Yes

Mounting Type:

Wall Mount

Housing Material:

Die-Cast Aluminum

Finish:

Bronze

IP Rating:

IP65

Wet/Damp Rating:

Wet Location

Certification:

cULus, DLC Premium (S-CW1MVQ)

Rated Hours:

50000

Beam Angle:

106

Distribution Type:

Type II

Photocell Included:

Yes - Bypassable

Dark Sky Compliant:

Yes (Full Cutoff, B2-U0-G2 BUG Rating)

Solar Powered:

false

Integrated Led:

true

Call for price

Description

The Satco/Nuvo 65-556 is a versatile LED full cutoff wall pack with field-selectable 80/100/120W wattage and 3000K/4000K/5000K color temperatures, delivering 12,107-17,789 lumens for superior outdoor security lighting. Featuring IP65 wet-rated die-cast aluminum housing in bronze finish, 0-10V dimming, bypassable photocell, and Type II distribution for dark sky compliance. Rated for 50,000 hours with 120-347V universal voltage and built-in 6kV surge protection.
