| Compliance |
| UL Listed | Suitable for dry and wet locations |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| Electrical |
| Driver | Constant Current, Class 2, 120V-277V, 50/60 Hz, 950mA, 120V: 0.6A, 208V: 0.321A, 240V: 0.278A, 277V: 0.223 |
| THD | 8.6% at 120V, 7.9% at 277V |
| Power Factor | 99.6% at 120V, 89.8% at 277V |
| Surge Protection | 4 kV Line-Line, 6 kV Line-Earth |
| Photocell | 120-277V Twistlock photocell included. Photocell is compatible with 120-277V. |
| LED Characteristics |
| LEDs | Long-life, high-efficiency, surface-mount LEDs |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 200 HPS |
| Construction |
| IES Classification | The Type V distribution produces light in a wide and uniform 360° pattern that is perfect for large outdoor areas such as parking lots, corporate parks and retail settings |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Housing | Precision die-cast aluminum housing and arm |
| Reflector | High-reflectance white paint |
| Lens | Flat polycarbonate lens |
| Gaskets | High-temperature silicone |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Optical |
| BUG Rating | B3 U3 G2 |
| Installation |
| Mounting | Mounts on pole |
