FEATURES:
- High-gloss white powder coated on die formed 16 gauge cold rolled steel housing.
- 0.125Ó Clear polycarbonate diffuser, tamper and high-impact resistant as standard. Optional 0.125Ó 100% DR clear prismatic acrylic diffuser.
- Ends with tapped holes to accommodate tamper-proof or regular screws. Tamper resistant (TR) option. Tamper proof driver cat. #TPDT required (sold separately).
- Optional rocker switch, grounded convenience outlet and GFCI.
- Optional available with integral ultrasonic occupancy sensor to sense motion within a space and automatically turn lights on.
- Comes in white end cap standard.
- Wall or ceiling mounted.
LAMP:
- Standard T8, T5, T5HO and PL-L lamps are available.
- Easy twist lock lamp sockets.
- Lamp not included.
ELECTRICAL:
- High power factor instant start electronic ballast for T8 lamps are sound rate A, minimum starting temperature 0¡F (-18¡C), <10% THD and input voltage ranges of 120 to 277 volts comes as standard.
- High power factor programmed start electronic ballast for T5 and T5HO lamps are sound rate A, minimum starting temperature 0¡F (-18¡C), <10% THD and input voltage ranges of 120 to 277 volts comes as standard.
- Ballast disconnect plug provided as standard.
LISTING:
- UL/CUL listed and labeled.
- Suitable for damp locations.
- Made in USA.
- ARRA compliant.
