| Compliance |
| UL Listed | Suitable for wet locations. Suitable for mounting within 4ft (1.2m) of the ground. |
| IP Rating | Ingress protection rating of IP66 for dust and water |
| ADA Compliant | SLIM™ is ADA Compliant |
| IESNA LM-79 & LM-80 Testing | RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80. |
| DLC Listed | This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.DLC Product Code: P0000171P |
| Electrical |
| Driver | Constant Current, Class 2, 120-277V, 50-60Hz, 120V: 0.20A, 208V: 0.11A, 240V: 0.10A, 277V: 0.09A |
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%. |
| THD | 15.21% at 120V, 10.6% at 277V |
| Power Factor | 97% at 120V, 94.6% at 277V |
| LED Characteristics |
| LEDs | Long-life, high-efficacy, surface-mount LEDs |
| Color Consistency | 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color |
| Color Stability | LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period |
| Color Uniformity | RAB's range of Correlated Color Temperature follows the guidelines for the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017. |
| Performance |
| Lifespan | 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations |
| Wattage Equivalency | Equivalent to 100W Metal Halide |
| Construction |
| Cold Weather Starting | The minimum starting temperature is -40°C (-40°F) |
| Maximum Ambient Temperature | Suitable for use in up to 40°C (104°F) |
| Housing | Precision die-cast aluminum housing |
| Lens | Tempered glass lens |
| Reflector | Specular thermoplastic |
| Gaskets | High-temperature silicone |
| Finish | Formulated for high durability and long-lasting color |
| Green Technology | Mercury and UV free. RoHS-compliant components. |
| Installation |
| Mounting | Heavy-duty mounting bracket with hinged housing for easy installation |
| Recommended Mounting Height | Up to 14 ft |
| Optical |
| BUG Rating | B1 U0 G0 |
