| General | |
| Status | Active |
| Watts | 20W |
| Volts | 12V |
| Shape | T3 |
| Filament | C-6 |
| Base | Bi Pin GY6.35 |
| ANSI Base | GY6.35 |
| Finish | Clear |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 300L |
| Beam Spread | 360 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 2000 |
| Product Category | Bi-Pin |
| Lamp Type | Bi-Pin |
| Technology | Halogen |
| Electrical | |
| Watts | 20W |
| Volts | 12V |
| Amps | 1.667A |
| Filament | C-6 |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 300L |
| Beam Spread | 360 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 2000 |
| Operating Position | Universal |
| Physical | |
| MOL | 1.25 |
| MOD | 0.38 |
| Shape | T3 |
| Base | Bi Pin GY6.35 |
| ANSI Base | GY6.35 |
| Finish | Clear |
| Lensed | Lensed Lamp |
| Weight (lb.) | 0.01 |
| Additional Information | |
| Warranty | Avg. Rated Hour Limited |
| Compliance | |
| Safety Listing | Not Listed |
| Location Rating | Damp |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| SDS Sheet | Halogen Double Ended or Pin Based Lamp |
| Packaging | |
| Each UPC | 045923041976 |
| Each Quantity | 1 |
| Each Length (in.) | 2.68 |
| Each Width (in.) | 0.87 |
| Each Height (in.) | 0.87 |
| Each Weight (lb.) | 0.01 |
| Each Cube (CuFt.) | 0.0012 |
| Pack Type | Box |
| Inner UPC | 20045923041970 |
| Inner Quantity | 48 |
| Inner Length (in.) | 5.59 |
| Inner Width (in.) | 3.86 |
| Inner Height (in.) | 5.79 |
| Inner Weight (lb.) | 0.53 |
| Inner Cube (CuFt.) | 0.0723 |
| Case UPC | 10045923041973 |
| Case Quantity | 960 |
| Case Length (in.) | 29.16 |
| Case Width (in.) | 8.27 |
| Case Height (in.) | 12.61 |
| Case Weight (lb.) | 11.03 |
| Case Cube (CuFt.) | 1.7598 |
Avg. Rated Hour Limited
