| General | |
| Status | Active |
| Watts | 100W |
| Volts | 120V |
| Shape | T3 |
| Filament | C-8 |
| Base | Double Ended Recessed Single Contact |
| ANSI Base | R7s |
| Finish | Clear |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 1650L |
| Beam Spread | 360 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 1500 |
| Product Category | Double Ended Halogen |
| Lamp Type | Double Ended Halogen |
| Technology | Halogen |
| Electrical | |
| Watts | 100W |
| Volts | 120V |
| Amps | 0.833A |
| Filament | C-8 |
| CCT (Kelvin) | 2900K |
| Temperature | Warm White |
| CRI | 100 |
| Lumens | 1650L |
| Beam Spread | 360 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 1500 |
| Operating Position | Universal |
| Physical | |
| MOL | 3.13 |
| MOD | 0.38 |
| Shape | T3 |
| Base | Double Ended Recessed Single Contact |
| ANSI Base | R7s |
| Finish | Clear |
| Lensed | Lensed Lamp |
| Weight (lb.) | 0.01 |
| Additional Information | |
| Warranty | Avg. Rated Hour Limited |
| Compliance | |
| Safety Listing | Not Listed |
| Location Rating | Damp |
| California Prop 65 | Lead |
| RoHS Compliant | Yes |
| SDS Sheet | Halogen Double Ended or Pin Based Lamp |
| Packaging | |
| Each UPC | 045923034220 |
| Each Quantity | 1 |
| Each Length (in.) | 0.63 |
| Each Width (in.) | 3.75 |
| Each Height (in.) | 7.68 |
| Each Weight (lb.) | 0.02 |
| Each Cube (CuFt.) | 0.0105 |
| Pack Type | Carded |
| Inner UPC | 20045923034224 |
| Inner Quantity | 12 |
| Inner Length (in.) | 3.74 |
| Inner Width (in.) | 4.53 |
| Inner Height (in.) | 7.68 |
| Inner Weight (lb.) | 0.75 |
| Inner Cube (CuFt.) | 0.0753 |
| Case UPC | 10045923034227 |
| Case Quantity | 240 |
| Case Length (in.) | 8.27 |
| Case Width (in.) | 18.91 |
| Case Height (in.) | 19.90 |
| Case Weight (lb.) | 15.44 |
| Case Cube (CuFt.) | 1.8010 |
Avg. Rated Hour Limited
