| General | |
| Status | Active |
| Watts | 8.5W |
| Fluorescent Equivalent | 18W |
| Volts | 120V-277V |
| Ballast Type | Type B |
| Shape | T5 |
| Base | 2G11 |
| ANSI Base | 2G11 |
| Finish | Frost |
| CCT (Kelvin) | 3000K/3500K/4000K/5000K/6500K |
| Temperature | Soft White to Daylight |
| CRI | 80 |
| Lumens | 930L/950L/980L/980L/980L |
| Beam Spread | 115 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | PL |
| Lamp Type | PL |
| Operating Position | Universal |
| Technology | LED |
| Electrical | |
| Watts | 8.5W |
| Fluorescent Equivalent | 18W |
| Volts | 120V-277V |
| Ballasting Requirements | Ballast Bypass |
| Ballast Type | Type B |
| Operating Frequency | 60Hz |
| CCT (Kelvin) | 3000K/3500K/4000K/5000K/6500K |
| Temperature | Soft White to Daylight |
| CRI | 80 |
| Lumens | 930L/950L/980L/980L/980L |
| Beam Spread | 115 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| THD | 20% |
| Operating Position | Universal |
| Operating Temperature | -20C (-4F) to +45C (+113F) |
| Physical | |
| MOL | 8.9 |
| MOD | 1.72 |
| Shape | T5 |
| Base | 2G11 |
| ANSI Base | 2G11 |
| Finish | Frost |
| Weight (lb.) | 0.18 |
| Additional Information | |
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5 Year Limited - 10 hr per day |
| Compliance | |
| Safety Listing | cULus - Certified; cULus - Classified; cRUus - Recognized Component |
| Location Rating | Damp |
| DLC ID | FALSE |
| NSF Approved | Yes |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| Packaging | |
| Each UPC | 045923184208 |
| Each Quantity | 1 |
| Each Length (in.) | 11.02 |
| Each Width (in.) | 1.89 |
| Each Height (in.) | 0.94 |
| Each Weight (lb.) | 0.23 |
| Each Cube (CuFt.) | 0.0113 |
| Pack Type | Box |
| Inner UPC | 20045923184202 |
| Inner Quantity | 10 |
| Inner Length (in.) | 11.61 |
| Inner Width (in.) | 4.33 |
| Inner Height (in.) | 5.43 |
| Inner Weight (lb.) | 2.41 |
| Inner Cube (CuFt.) | 0.1580 |
| Case UPC | 10045923184205 |
| Case Quantity | 20 |
| Case Length (in.) | 12.40 |
| Case Width (in.) | 9.45 |
| Case Height (in.) | 6.22 |
| Case Weight (lb.) | 5.62 |
| Case Cube (CuFt.) | 0.4218 |
5 Year Limited - 10 hr per day
