| General | |
| Status | Active |
| Watts | 24W |
| Incandescent Equivalent | 100W |
| Fluorescent Equivalent | 75W |
| Volts | 120V-277V |
| Ballast Type | Type B |
| Shape | T8 |
| Base | Recessed Double Contact HO/VHO |
| ANSI Base | R17d |
| Nominal Length | 60 |
| Finish | White |
| CCT (Kelvin) | 4000K/5000K/6500K |
| Temperature | Cool White to Daylight |
| CRI | 83 |
| Lumens | 3350L/3450L/3300L |
| Beam Spread | 360 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | Linear |
| Lamp Type | Linear |
| Technology | LED |
| Electrical | |
| Watts | 24W |
| Incandescent Equivalent | 100W |
| Fluorescent Equivalent | 75W |
| Volts | 120V-277V |
| Ballasting Requirements | Ballast Bypass |
| Ballast Type | Type B |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 4000K/5000K/6500K |
| Temperature | Cool White to Daylight |
| CRI | 83 |
| Lumens | 3350L/3450L/3300L |
| Beam Spread | 360 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| THD | 25% |
| Operating Temperature | -20C (-4F) to +45C (+113F) |
| Physical | |
| MOL | 57.81 |
| MOD | 1.13 |
| Nominal Length | 60 |
| Shape | T8 |
| Base | Recessed Double Contact HO/VHO |
| ANSI Base | R17d |
| Finish | White |
| Material | Polycarbonate (PC) |
| Lens Finish | Frost |
| Lens Material | Plastic |
| Weight (lb.) | 0.95 |
| Additional Information | |
| Tube Guard Use | No |
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5 Year Limited - T8 LED Bulbs |
| Compliance | |
| Safety Listing | cULus - Certified; cULus - Classified; cRUus - Recognized Component |
| Location Rating | Damp |
| DLC Approved | No |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| NSF Approved | ETL Sanitation listed (conforms to NSF) |
| SDS Sheet | LED Lamp |
| Packaging | |
| Each UPC | 045923164361 |
| Each Quantity | 1 |
| Each Length (in.) | 60.00 |
| Each Width (in.) | 1.15 |
| Each Height (in.) | 1.15 |
| Each Weight (lb.) | 1.50 |
| Each Cube (CuFt.) | 0.0459 |
| Pack Type | Egg Crate |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923164368 |
| Case Quantity | 10 |
| Case Length (in.) | 60.00 |
| Case Width (in.) | 7.87 |
| Case Height (in.) | 4.92 |
| Case Weight (lb.) | 15.00 |
| Case Cube (CuFt.) | 1.3445 |
5 Year Limited - T8 LED Bulbs
