| General | |
| Status | Active |
| Watts | 4.5W |
| Incandescent Equivalent | 35W |
| Volts | 12V |
| Shape | T6 |
| Base | Bi Pin GY6.35 |
| ANSI Base | GY6.35 |
| Finish | Clear |
| CCT (Kelvin) | 3000K |
| Temperature | Soft White |
| CRI | 80 |
| Lumens | 430L |
| Beam Spread | 300 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 25000 |
| Product Category | Tubular |
| Lamp Type | Tubular |
| Technology | LED |
| Electrical | |
| Watts | 4.5W |
| Incandescent Equivalent | 35W |
| Volts | 12V |
| Operating Frequency | 60Hz |
| CCT (Kelvin) | 3000K |
| Temperature | Soft White |
| CRI | 80 |
| Lumens | 430L |
| Beam Spread | 300 |
| Dimmable | Yes-Dimmable |
| Dimming Type | Phase cut |
| Dimming Note | Check the transformer/driver MFG for dimmer compatibility |
| Hours Rated | 25000 |
| Operating Temperature | -20C (-4F) to +40C (+104F) |
| Physical | |
| MOL | 1.81 |
| MOD | 0.73 |
| Shape | T6 |
| Base | Bi Pin GY6.35 |
| ANSI Base | GY6.35 |
| Finish | Clear |
| Housing Color | White |
| Weight (lb.) | 0.02 |
| Additional Information | |
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| Warranty | 3 Year Limited - Mini LED Pin Base |
| Compliance | |
| Safety Listing | cULus - Certified; cULus - Listed |
| Location Rating | Damp |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| Packaging | |
| Each UPC | 045923123184 |
| Each Quantity | 1 |
| Each Length (in.) | 1.50 |
| Each Width (in.) | 1.50 |
| Each Height (in.) | 2.95 |
| Each Weight (lb.) | 0.04 |
| Each Cube (CuFt.) | 0.0038 |
| Pack Type | Box |
| Inner UPC | 20045923123188 |
| Inner Quantity | 20 |
| Inner Length (in.) | 8.07 |
| Inner Width (in.) | 3.35 |
| Inner Height (in.) | 6.42 |
| Inner Weight (lb.) | 0.82 |
| Inner Cube (CuFt.) | 0.1004 |
| Case UPC | 10045923123181 |
| Case Quantity | 200 |
| Case Length (in.) | 17.44 |
| Case Width (in.) | 8.66 |
| Case Height (in.) | 13.62 |
| Case Weight (lb.) | 9.10 |
| Case Cube (CuFt.) | 1.1904 |
3 Year Limited - Mini LED Pin Base
